Page 1/7
What s In The Box’
Please inspect the contents of your shipped package to ensure you have received everything that
is listed below.
All rights reserved.
No part of this document may be reproduced, stored in a retrieval system, or transmied by any form or by any means,
electronic, mechanical, photo copying, recording, or otherwise, except as may be expressly permied by the applicable copyright -
statutes or in wring by the Publisher.
CF Carbon Fiber Star Ring for Handheld Gimbal
Camera Stabilizers & Body Support Rigs (P STRG CF)- -
A s s e m b ly Ma n u a l
2 x L type Allen key-
(Size: 5mm, 3mm)-
Top CF Star Ring
4 x Allen Bolts
(Size: 4 x 16)
4 x Allen Bolts
(Size: 3 x 10)-
4 x Allen Bolts
(Size: 3 x 12)
4 x Allen Bolts
(Size: 4 x 20)
1 x T type Allen key-
(Size: 2.5mm)-
Boom CF Star Ring Bag Packing
2
FUNCTION
Stands in Upright Posions with
Addion Mounng
keep the setup upright without using a
stand by providing a wide base that does
not fall forward or backward.
Foot Clamps
Index marking to
enable the operator
to eciently ax the
clamps and
quick release adapter -
where they were the
last me they were
shoong.
Scalling
Eortlessly aach to most body
support rigs and Camera can be move
exible and adjust the posions.
Spool Clamps
Quick Release Adapter
Index Marking
Index marking helps to
adjust the posions of
spool clamps and
adapter.
Underslung and over slung mode using the quick- -
release adapter with M3 and M4 threads
Wide compability movi & R2 Quick
release plate with addional accessory
security, control over your 2 axis and -
3 axis gimbals with the adapter-
3
• Aach the top CF & boom CF Star Ring.
NOTE: The portable and travel friendly design -
can be detached into two pieces to ensure
comfortable carriage to dierent shoong
locaons.
SetupCF Carbon Fiber Star Ring
• All three foot clamps have been removed, as
shown in the image.
• Aer aaching the Star Ring, ghten the allen
bolts it using the 2.5mm Allen key, as shown
in the image.
• The Star Ring has sturdy spool clamps that
easily aach to most body support rigs.
Features: The Spool clamp can be posioned at
the same place where they were the last me
you were shoong using the index markings.
• Remove the aached Foot clamp on the Top
CF Star ring by loosening it.
• Repeat the same process with the other two
foot clamps.
• Aach the foot clamps with the boom CF
Star Ring.
Product Specifications
| Brand: | Proaim |
| Category: | Tripod |
| Model: | P-STRG-CF |
