Page 1/8
1
What s In The Box’
Please inspect the contents of your shipped package to ensure you have received everything that
is listed below.
All rights reserved.
No part of this document may be reproduced, stored in a retrieval system, or transmiîž©ed by any form or by any means,
electronic, mechanical, photo copying, recording, or otherwise, except as may be expressly permiîž©ed by the applicable copyright -
statutes or in wring by the Publisher.
A s s e m b l y M a n u a l
Flowline Master with Edge V1 Stabilizaon Arm
(FLN MSTR EGV1) - -
2 x Washers
2 x Velcro
2.5mm Allen Key
2mm Allen Key
Edge V1
Stabilizaon
Arm
Height Riser
Flycam
Flowline
Master
Support Bar
Camera Hook
Side Support
Adjustment
Balance Adjustment
Knob
2
• Similarly, remove the second screw.
• Now, remove the Hook from the Flowline
Support Arm.
• As shown in the image, take the Cord
bundle out from the Cup and pull the Cord
unl a Cord lock comes out.
• Separate the Cord and the Cord lock.
• Keep the lock aside to re aach it later.-
Flowline Master with Edge Setup
• Loosen the screw of the Camera Hook
aîž©ached to the Flowline Support Arm using
the Allen key.
• Similarly, separate the Cord from the Cup to
mount it back later.
NOTE: It is recommended to aîž©ach the minimum required weight (4kg / 8lb) for pulling down the balancing
rope to ensure proper operaon of your Flycam Flowline system.
3
• To detach the Flowline Support Rod,
pull it upwards.
• To detach the extension from the Support
Rod of the Vest, remove its screw using a
screwdriver.
• Detach the extension from the Support Rod
and align the cord with the height riser, as
shown in the image.
• Aach the extension with the height riser
and push it inside.
Feature: Height riser that oers up to 4" of
vercal extension for taller operators and a
lockable hook to secure any camera, gimbal,
or cage eortlessly.
• Dissemble the Camera Hook and the
Support Rod from the Vest.
• Insert a screw in the Support rod and
ghten it using the screwdriver.
Product Specifications
| Brand: | Flycam |
| Category: | Tripod |
| Model: | Flowline Master |
