Flycam Flowline Starter Manual
Read below 📖 the manual in Italian for Flycam Flowline Starter (8 pages) in the Tripod category. This guide has been helpful for 8 people and has been rated 4.5 stars on average by 2 users
Page 1/8
1
What s In The Box’
Please inspect the contents of your shipped package to ensure you have received everything that
is listed below.
All rights reserved.
No part of this document may be reproduced, stored in a retrieval system, or transmiîž©ed by any form or by any means,
electronic, mechanical, photo copying, recording, or otherwise, except as may be expressly permiîž©ed by the applicable copyright -
statutes or in wring by the Publisher.
Flowline Starter with Edge V1 Stabilizaon Arm
(FLCM FLN EGV1) - -
Flycam Flowline
Starter
Edge V1 Arm
Bag Packing
2 x Washers
2mm Allen Key
2.5mm Allen Key
2 x Velcro
A s s e m b l y M a n u a l
2
• Similarly, remove the second screw.
• Now, remove the Hook from the Flowline
Support Arm.
• As shown in the image, take the Cord
bundle out from the Cup and pull the Cord
unl a Cord lock comes out.
• Separate the Cord and the Cord lock.
• Keep the lock aside to re aach it later.-
Flowline Starter with Edge Setup
• Loosen the screw of the Camera Hook
aîž©ached to the Flowline Support Arm using
the Allen key.
• Similarly, separate the Cord from the Cup to
mount it back later.
NOTE: It is recommended to aîž©ach the minimum required weight (3kg / 6.6lb) for pulling down the
balancing rope to ensure proper operaon of your Flycam Flowline system.
3
• To detach the Flowline Support Rod
pull it upwards.
• To detach the extension from the Support
Rod of the Vest, remove its screw using a
screwdriver.
• Detach the extension from the Support Rod
and align the cord with the height riser,
(Not Included) as shown in the image.
• Dissemble the Camera Hook and the
Support Rod from the Vest.
• Aach the extension with the height riser
(Not Included) and push it inside.
Feature: Height riser that oers up to 4" of
vercal extension for taller operators and a
lockable hook to secure any camera, gimbal,
or cage eortlessly.
Product Specifications
| Brand: | Flycam |
| Category: | Tripod |
| Model: | Flowline Starter |
