Page 1/6
Owner’s
Manual
Video Tripod Head
VPH-20
• VPH-20 Video Pan Head
• 3/8” and ¼”-20 reducing bushing
• Quick-release plate
Box Contents
Key Features
Thank you for choosing Magnus.
Congratulations on your purchase of the VPH-20
Video Pan Head by Magnus.
All Magnus Video Heads are designed to balance
features professionals want with the affordability they
need. They’re durable enough to provide many years
of trouble-free service and enjoyment. Please carefully
read these instructions before setting up and using
your Video Pan Head.
Pan Lock
Full 360°
pan range
180°
Tilt range
Tilt Lock
Tilt-Tension Adjustment Knob
Auto-lock
Quick-release
mounting
Tilt-Tension
Adjustment
Knob
Padded grip
handle
Image is for illustration purposes only.
Features vary by model
Attaching the VPH-20 to Your Tripod
1 Your VPH-20 comes with a bushing that
adapts the 3/8 tripod mount to use with
1/4-20 screws.
2 Choose the bushing
that fits your tripod.
Screw one side into the
base of the VPH-20,
and then attach the
VPH-20 onto the tripod.
If you’re using a very
small tripod, you may find it easier to hold the VPH-
20 steady and screw on the tripod.
Mounting Your Camera on the VPH-20
1 Firmly grasp the quick-release lever and rotate it
180° so the flat side is against the quick-release
plate, and it locks into place. This will release the
plate, and it will pop up. Slide the plate forward and
pull up on it to remove from the VPH-20.
2 Use the thumbscrew on the quick-release plate
to attach it to your camera. Many video cameras
have an additional space that accommodates the
retractable alignment pin on the plate. Take care
that it fits into place. Make sure the thumbscrew is
flush against the bottom of the plate.
Product Specifications
| Brand: | Magnus |
| Category: | Tripod |
| Model: | VPH-20 |
