Page 1/8
Please inspect the contents of your shipped package to ensure you have received everything that is listed
below.
All rights reserved.
No part of this document may be reproduced, stored in a retrieval system, or transmied by any form or by any means,
electronic, mechanical, photo copying, recording, or otherwise, except as may be expressly permied by the applicable copyright -
statutes or in wring by the Publisher.
What s In The Box’
A s s e m bl y M a n ua l
Rocker Plate System
Rocker Camera Plate System P RCPL- -01
Handle
2 x Camera Bolts
(Size: 3/8”)
2
INDEX
Sr. No Particulars Page No.
1. Rocker Camera Plate System Setup 3
2. Handle Assembly 3
3. Euro Mounng 3 4-
4. Euro/Elemac Base Mount Setup 4
5. Camera Mounng Setup 4 5-
6. 90° Tilt & 360° Pan Rotaon 5 6-
7. Dolly Setup 6 7-
8. Camera Mounng Setup 7
9. Final Setup 8
3
Feature: Rosee knob allows you to aach
included handle on the le & right hand -
posion according to your preference.
• Now loosen the knob and extend the length
as desired. Once adjusted, ghten the
handle knob securely.
Feature: The handle's length can be easily
adjusted using convenient knobs, ensuring
both control and comfort when capturing
your best shots.
• To adjust the handle posion, loosen the
Rosee Knob, and once the handle is in the
desired posion, ghten the Rosee Knob
securely.
Rocker Camera Plate System Setup
• Insert the handle into the Rocker Plate
System and ghten the Rosee Knob to
secure it in place.
Handle Assembly
• Mount the Euro Adapter on (Not Included)
the boom side of the rocker plate system
and insert screws 3/8” (Not Included)
matching the threads.
Euro Mounng
Product Specifications
| Brand: | Proaim |
| Category: | Tripod |
| Model: | P-RCPL-01 |
