Proaim P-LLBT-150 Manual
Read below 📖 the manual in Italian for Proaim P-LLBT-150 (6 pages) in the Tripod category. This guide has been helpful for 8 people and has been rated 4.5 stars on average by 2 users
Page 1/6
Please inspect the contents of your shipped package to ensure you have received everything that is listed
below.
HD 150mm Bowl Baby Camera Tripod Stand w
Lever Fricon and Aluminum Spreader (P LLBT- - -150)
All rights reserved.
No part of this document may be reproduced, stored in a retrieval system, or transmied by any form or by any means,
electronic, mechanical, photo copying, recording, or otherwise, except as may be expressly permied by the applicable copyright -
statutes or in wring by the Publisher.
What s In The Box’
HD 150mm Bowl Baby Camera Tripod Stand
with Lever Fricon
Spanner Size: 13mm
Aluminium Spreader
A s s e m b ly Ma n u a l
2
Aluminum Spreader Setup
• Extend the Spreader on the oor and loosen
all three knobs.
NOTE: The Spreader aaches to the spiked legs
of the spreader to provide precise customizaon
of the tripod's length and stability.
• Aer loosening the knobs, extend the
Spreader per your requirement.
• You can lock the posion using the locking
knobs present on each arm.
NOTE: The arms of the Spreader can easily
telescope out from 41cm/16 to 66cm/26” ”
radius, oering a broader footprint to create a
secure and steady base for the tripod.
Extendable adjustment via the provided locking knobs of Spreader
3
• Loosen all three adjustment knobs to set the
desired height of the Stand.
NOTE: One stage telescopic design with fricon -
knob extends up to 6 inches to capture
low angle shots, and conversely, it can be easily -
extended up to 34 inches for greater elevaon.
• Aer seng the height, ghten the knobs to
secure the Stand, as shown in the image.
NOTE: Locking pins on each leg secures the
adjusted height, prevenng them from
retracng under load.
• Unlock the red knob to adjust the Tripod s legs ’
according to your requirement.
• Aer adjusng the Tripod legs, re-lock the
knob, as shown in the image.
• Mount the Tripod on the aluminum Spreader
by equally aligning them.
• Aer mounng the Tripod, properly secure it
using the rubber gripper.
150mm Bowl Baby Camera Tripod Stand Setup
Product Specifications
| Brand: | Proaim |
| Category: | Tripod |
| Model: | P-LLBT-150 |
