Please inspect the contents of your shipped package to ensure you have received everything that is listed
below.
Smart Side Camera Car Mount Hostess
Tray Kit (CM- -SSHT 01)
A s s e m b ly Ma n u a l
All rights reserved.
No part of this document may be reproduced, stored in a retrieval system, or transmiîž©ed by any form or by any means,
electronic, mechanical, photo copying, recording, or otherwise, except as may be expressly permiîž©ed by the applicable copyright -
statutes or in wring by the Publisher.
What s In The Box’
Cheese Plate With Mitchell Mount
2 x Feet Holder
Extruded Rail
2 x Plaîžžorm
Extruded Rail
2 x Safety Belts
2 x Door Hooks
3 x Centre
Support
Extruded Rail
2 x Side
Support
Extruded Rail
2 x Adjustable Supporve
Feet
6mm Allen Key
4 x Bolts with Washer
2
FUNCTION
Gear for Tilng Movement
Extruded Rail
Cheese Plate with Mitchell Mount
for Camera Mounng
Cheese Plate
Perfectly Aîž©aches to Car Door
Via L Shaped Door Hooks-
Hooks
Adjustable Supporve Feet
Feet
Knob
Perfectly Secure the Rails
Allows rm mounng for
smooth shots
Mitchell Mount
3
Hostess Tray Kit Setup
• Using the Allen key, loosen the clamp bolt in
the Feet Holder Extruded Rail.
• Insert the adjustable supporve feet in the
clamp.
• Re-ghten the bolt using to Allen key to secure
the feet.
• Loosen the bolt to slide up and down.
• The Feet Holder Extruded rail clamp can slide
up or down per your requirement.
• Loosen the knob of the Centre Support
Extruded Rail.
• Remove the bolt from the rail, as shown in the
image.
