Proaim CM-BLPR-01 Manual
Read below 📖 the manual in Italian for Proaim CM-BLPR-01 (5 pages) in the Tripod category. This guide has been helpful for 10 people and has been rated 4.5 stars on average by 2 users
Page 1/5
What s In The Box’
Please inspect the contents of your shipped package to ensure you have received everything that is listed
below.
Ballpro Camera Sucon Car Mount w
Vibraon Isolator (CM- -BLPR 01)
A s s e m b l y M a n u a l
All rights reserved.
No part of this document may be reproduced, stored in a retrieval system, or transmied by any form or by any means,
electronic, mechanical, photo-copying, recording, or otherwise, except as may be expressly permied by the applicable copyright
statutes or in wring by the Publisher.
3 x Allen Bolts
(Size: x 6)1/4”-20 x 1 1/4” & 2.5 -
2 x Allen Key
(Size: 4mm, 2.5mm)
DJI QR Plate-
P QRG-
Bolt Size
3/8”, 1/4”
4 x Yellow Dust Covers
Foam With Bag Packing Sucon Car Mount
2
Ballpro Camera Setup
• Place your rst sucon cup in the selected
Posion from where you want to shoot.
• Similarly, remove rest of the yellow dust
covers of the sucon mount, as shown in the
image.
• Sucon Car Mount is now properly placed on
the car.
• Remove the yellow dust cover of Sucon Car
Mount.
• Press down the sucon cup and keep pushing
the pump to rmly x it on the surface. Repeat
this process for all the sucon cups.
Cauon: Recheck the Pump every 90 minutes. If
the red line is visible, Re pump the cup without -
losing the remaining vacuum ll the Red Line
disappears.
• Secure the movement of the ball joint with the
help of the Ratchet knob of the Telescopic
legs.
3
• Place the DJI QR Plate on the Sucon Car -
Mount.
NOTE: Two Ratchet knobs are provided in
Sucon Car Mount, with the help of the boom
knob, you can change the ball joint movement of
the telescopic legs.
• Follow the same process for other Allen Bolts.
• DJI QR Plate is properly aached on the -
Sucon Car Mount.
• Then insert Allen bolts and ghten with the
help of 4mm Allen key.
• Then aach the (P-QRG) plate with Ronin
Gimble and ghten it properly
(Not Included) -
with the help of a Screw Driver.
Product Specifications
| Brand: | Proaim |
| Category: | Tripod |
| Model: | CM-BLPR-01 |
