Radianâ„¢
TRIPOD LEVELING HEAD
PRODUCT MANUAL
2
Quick-Release
Locking Knob Bubble Level
Leveling Head
Locking Knob
Quick-Release Plate
Counterweight Hook
To help stabilize the tripod in windy
conditions, hang a weight from the
Counterweight Hook.
4
BASIC ADJUSTMENTS
Tilt Action
The leveling head’s tilt can be adjusted by unlocking the
leveling head. This allows you to position your optic at the
desired angle, or pan the optic while glassing.
• To unlock the leveling head, rotate the Leveling Head
Locking Knob clockwise (viewing from the top) until
the leveling head moves freely. Adjust to your desired
position and lock the leveling head.
• To lock the leveling head, rotate the Leveling Head
Locking Knob counter-clockwise (viewing from the top)
until you feel tension on the knob. Do not overtighten.
Rotate the
Leveling Head
Locking Knob to
adjust position or
lock in place.
Product Specifications
| Brand: | Vortex |
| Category: | Tripod |
| Model: | Radian |
