iOptron® MiniPier
Instruction Manual
Product #8032
®
MiniPier 8032
iOptron® MiniPier is designed for iOpt EM60, iEQ45, iEQ30ron GOTO mounts, which includes C 1,
MiniTower and AZ mount Pro mount. It can be used with a MiniTower/MiniTower Pro/iEQ45 tripod,
pier or Tri-pier to raise 8” in height.
Parts include:
The actual parts included in the package depend on the mount type:
1. 1x MiniPier Body
2. 2x M8 hex head screws for iEQ45 tripod/pier mounting
3. 3x M10 hex head screws for MiniTower tripod mounting
4. 1x iEQ45 center stud for iEQ45/CEM60 (optional)
5. 1X iEQ30 center stud for iEQ30 (optional)
6. 1x M12 Center Bolt with turning lever for MiniTower/MiniTower Pro (optional)
Specifications:
Pier diameter: 5.7" (144mm) with 6" (150mm) Flange plates
Pier height: 8" (203mm)
1 For an iEQ30 mount, an iEQ45/MT/MTP tripod or a pier/tri-pier is needed.
MiniPier for iEQ45/iEQ30
The assemble example shown here is for
installing a MiniPier onto an iEQ45/CEM60
tripod. For an iEQ30 mount, an
iEQ45/MT/MTP tripod or a pier/tri-pier is
needed.
1. Extend the tripod legs and adjust the
height of the tripod. Secure the tripod.
Remember that the MiniPier will add 8
inch in height. Remove the alignment
peg from the iEQ45 tripod head.
2. Release three locking screws located at
the bottom of the MiniPier body. Put the
Base Flange onto the tripod head. Using
two M8 hex head screws to secure the
base flange on to the iEQ45 tripod.
3. Put the MiniPier body onto the Base
Flange and secure it using three locking
screws.
4. Final adjust the tripod height and level
the tripod with MiniPier before mounting
the iEQ45 mount.
Example: an iEQ45 mount on a
MiniPier with an iEQ45 tripod
Example: an iEQ30 mount on a
MiniPier with an iEQ45 tripod
M8 screw
Lockin
g
screw
