DP Pro Plenum Series Cable Guide
The Extron DP Pro Plenum cables support digital video resolutions up to 8K/30 at 4:4:4 while
maintaining a small and exible diameter (0.18" [4.7 mm]) ideal for an installation with a tight
bend radius. These unidirectional, plenum rated cables are offered in seven lengths from
25feet (7.6 m) to 150 feet (45.7 m):
Model Description
DP Pro P/25 DP Pro Plenum Cable M-M 25 feet (7.6 m)
DP Pro P/35 DP Pro Plenum Cable M-M 35 feet (10.6 m)
DP Pro P/50 DP Pro Plenum Cable M-M 50 feet (15.2 m)
DP Pro P/75 DP Pro Plenum Cable M-M 75 feet (22.8 m)
DP Pro P/100 DP Pro Plenum Cable M-M 100 feet (30.4 m)
DP Pro P/125 DP Pro Plenum Cable M-M 125 feet (38 m)
DP Pro P/150 DP Pro Plenum Cable M-M 150 feet (45.7 m)
NOTE: The DP Pro Plenum cables are unidirectional from source to display.
DP Pro Plenum Series Cable Guide,
Continued
NOTES:
• The DP Pro Plenum connectors are labeled Source and Display. Be sure to connect
them accordingly for proper signal ow.
• Insert the connector with the blue ring into the source.
Source
DP Pro Hybrid Cable
Unidirectional Display
Blue ring indicates Source side.
© 2020 Extron Electronics — All rights reserved. www.extron.com
All trademarks mentioned are the property of their respective owners.
Worldwide Headquarters: Extron USA West, 1025 E. Ball Road, Anaheim, CA 92805, 800.633.9876
68-3422-01 Rev. A
02 20
