Page 1/2
www.LogiLink.com
* The specifications and pictures are subject to change without notice.
*All trade names referenced are the registered namework of their respective owners.
The optimized HDMI cable is specially designed for the
latest HDMI version. The HDMI Ethernet Channel technology
consolidates video, audio, and data streams into a single HDMI
cable, and enables high-speed networking at up to 100 Mb/
sec. Audio Return Channel allows an HDMI-connected TV with a built-in tuner
to send audio data "upstream" to a surround audio system. Imaging 3D via
HDMI and support all HDTV formats including 480p, 720p, 1080i, 1080p and
4K (4096 x 2160). In addition to RGB color and x.v.Color, it supports for three
additional color spaces (sYCC60, Adobe RGB, and Adobe YCC601), enabling to
deliver better accurate color on an HDTV.
Specification:
• HDMI type A male to Mini HDMI type C male cable
• Connector: Gold Plated
• Color: Black
• OD: 6.0MM
• HDMI M 19P Solder Type, Insulation: Black, Shell Gold Plated
• Mini HDMI M 19P Solder Type, Insulation: Black, Shell Gold Plated
• Cable:
- CH0021-24: (30AWG*lPR+AL)*4C+(30AWG*lPR+EAM)*lC+30AWG*4C+EA
- CH0025: (28AWG*lPR+AL)*4C+(30AWG*lPR+EAM)*lC+30AWG*4C+EA
t No. CH0021 to CH0025
HDMI to Mini HDMI Cable
- 1 -
www.LogiLink.com
* The specifications and pictures are subject to change without notice.
*All trade names referenced are the registered namework of their respective owners.
Electrical Test:
1. 100% Test (Open, Short, Mis Wire)
2. Contact Resistance: 3 ohm max.
3. Insulation Resistance: 10M ohm min.
4. Hi-Pot Test: DC 300V/10ms
Packaging Information:
Model
Name
L T Packing
Weight
Q'ty Carton
Dimension
Carton
Weight
EAN Code
CH0021 100cm 15mm 0.057kg 140pcs 500x320x210 mm 9.0kgs 4260113573273
CH0022 150cm 20mm 0.075kg 100pcs 500x320x210 mm 8.5kgs 4260113573280
CH0023 200cm 30mm 0.091kg 80pcs 500x320x210 mm 8.3Kgs 4260113573297
CH0024 300cm 40mm 0.139kg 60pcs 500x320x210 mm 8.8kgs 4260113573303
CH0025 500cm 50mm 0.213kg 40pcs 500x320x210 mm 9.5kgs 4260113573310
t No. CH0021 to CH0025
HDMI to Mini HDMI Cable
- 2 -
Product Specifications
| Brand: | Logilink |
| Category: | Cables for PCs and peripherals |
| Model: | CH0022 |
