Page 1/30
Manual
Vibration Analyser
PCE-VT 204
PCE Americas Inc.
711 Commerce Way
Suite 8
Jupiter
FL-33458
USA
From outside US: +1
Tel: (561) 320-9162
Fax: (561) 320-9176
info@pce-americas.com
www.pce-instruments.com/english
www.pce-instruments.com
PCE Instruments UK Ltd.
Units 12/13
Southpoint Business Park
Ensign way
Hampshire / Southampton
United Kingdom, SO31 4RF
From outside UK: +44
Tel: (0) 2380 98703 0
Fax: (0) 2380 98703 9
info@pce-instruments.com
TABLE OF CONTENTS
1 FEATURES................................................................
.
1
2 SPECIFICATIONS......................................................
.
3
3 FRONT PANEL DESCRIPTION..................................... 7
3-1 Display..............................................................................................
.
7
3-2 Power button ( vibration )...................................................................7
3-3 Hold/ESC/Zero button.........................................................................7
3-4 Eenter/REC button.............................................................................
.
7
3-5 Function/Send button......................................................................... 7
3-6 Unit/Lo
gg
er button............................................................................. 7
3-7 Operation button ( tachometer ).........................................................
.
7
3-8 Surface speed wheel ( contact tach. ).................................................. 7
3-9 RPM adapter ( contact tach. ).............................................................
.
7
3-10 Protection cover ( contact tach. ).......................................................
.
7
3-11 Screw for protection cover.................................................................
.
7
3-12 Cable plu
g
( vibration sensor )...........................................................
.
7
3-13 Vibration sensor................................................................................
.
7
3-14 Ma
g
netic base................................................................................... 7
3-15 Input socket ( vibration sensor ).........................................................7
3-16 Laser li
g
ht beam ( photo tach. ).........................................................
.
7
3-17 Photo tach. detectin
g
sensor.............................................................. 7
3-18 IR probe input socket........................................................................
.
7
3-19 RS-232 output terminal...................................................................... 7
3-20 Battery cover/battery compartment.................................................... 7
3-21 Cone rubber ( RPM adapter ).............................................................
.
7
3-22 Funnel rubber ( RPM adapter )........................................................... 7
4 VIBRATION MEASURING PROCEDURE........................ 9
5 TACHOMETER MEASURING PROCEDURE....................
.
20
6 IR TEMP. MEASURING PROCEDURE...........................
.
24
7 RS232 PC SERIAL INTERFACE....................................24
8 BATTERY REPLACEMENT...........................................
.
26
9 OPTIONAL ACCESSORIES..........................................
.
26
10 CLASSIFICATION RANGES ( Vibration ).....................
.
27
11 SENSITIVITY RELATIVE TABLE ACCORDING
ISO 2954 ( Vibration ).............................................
.
28
1. FEATURES
Vibration function :
* Applications for industrial vibration monitoring :
All industrial machinery vibrates. The level of vibration
is a useful guide to machine condition. Poor balance,
misalignment & looseness of the structure will cause
the vibration level increase, it is a sure sign that the
maintenance is needed.
* Acceleration range : 200 m/s^2.
* Velocity range : 200 mm/s.
* Displacement ( p-p ) range : 2 mm.
* Metric and imperial display unit .
* RMS measurement for Acceleration and Velocity.
* Peak to peak measurement for Displacement.
* Peak function for Acceleration and Velocity.
* Max. hold function for Acceleration ( peak ),
Velocity ( peak ) and Displacement ( peak to peak ).
* Frequency range 10 Hz - 1 kHz, sensitivity relative
meet ISO 2954.
* Zero function, executed by front buttons.
* Data logger function with flexible sampling time
selection, can save max. 1000-point data into the
memory circuit.
* Data hold button to freeze the desired reading.
* Memory function to record maximum and minimum
reading of RMS value ( Acc., Vel. ) or Displacement ( p-p ).
* Auto shut off saves battery life.
* Professional vibration meter supply with separate
vibration sensor & magnetic base, full set.
1
