INSTRUCTION MANUAL
Thermal Imager for
Android
®
Devices
• 10,800 PIXELS TO
TROUBLESHOOT
HOT AND COLD
SPOTS
• CAPTURE,
STORE, AND
SHARE IMAGES,
VIDEO, AND
TIME-LAPSE VIDEO
• DIFFERENTIAL AND
TOUCH SCREEN TEMPERATURE
• HIGH AND LOW TEMPERATURE
ALARMS
• SELECTABLE COLOR PALETTES
• COMPATIBLE WITH MOST
ANDROID®* DEVICES
TI
TI
TI
TITI
220
-4° – 752°F
-20° –
400°C
2m
*Android® version 6.0 or higher
2
GENERAL SPECIFICATIONS
Klein Tools TI220 Thermal Imager allows easy capture, storage, and sharing
of images and video, including time-lapse video, for instant troubleshooting
on your Android
®
device. Excellent resolution of over 10,800 pixels, with your
choice of color palettes. The meter features differential temperature, touch-point
temperature, and high and low temperature alarms.
TI220 has USB-C and micro-USB connections for most Android
®
smart phones
and devices. The camera output is displayed on the Android
®
device using the
Klein Tools Thermal Imager App, available for free from Google Play
TM
store.
• Environment: Indoor or outdoor
• Operating Altitude: 6562 ft. (2000 m)
• Relative Humidity: <95% non-condensing
• Operating Temp: 32° to 122°F (0° to 50°C)
• Storage Temp: 14° to 140°F (-10° to 60°C)
• Sensor Resolution: 10800 pixels
• Pixel size: 17μm
• Spectral Response: 8 to 14μm
• Field of View (FOV): 50°
• Frame Rate: 9 Hz
• Sensitivity: <60 mK at 25°C
• Temperature Range: °-4° to 752° F (-20 to 400° C)
• Temperature Resolution: 0.1°F, 0.1°C
• Temperature Accuracy: +/-2° or 2% (whichever is greater)
NOTE: Not calibrated below 14°F (-10°C)
• Temperature Display: Differential temperature, high, center, and
low cross hairs, and user-selectable temperature
• Temperature Settings: °F / °C
• Emissivity: 0.1 to 0.99 adjustable (0.95 default)
• Color Palettes: Ironbow, Rainbow, Grayscale
• Mobile Device: Android® 6.0 or higher
• Mobile App: Google Play supported
• Image Format: JPG
• Video Format: MP4
• Dimensions: 1.07" × 2.13" × 0.73" (27.2 × 54.0 × 18.5 mm)
• Weight: 1.08 oz. (30.7 grams)
• Pollution degree: 2
• Drop Protection: 6.6 ft. (2m)
Specifications subject to change.
ENGLISH
Android® a is a registered trademark of Google LLC.
Google Playâ„¢ store is a trademark of Google LLC.
3
WARNINGS
To ensure safe operation and service, follow these instructions.
• Read the instructions to ensure safe operation.
• Always wear approved eye protection.
• Do not use if the housing is damaged in any way.
• DO NOT use if the USB-C connector, micro-USB connector/adapter is
damaged in any way.
• There are no user-serviceable parts inside. DO NOT open or attempt to repair.
NOTE: Do not point the camera at the sun or any other strong energy source.
This can affect the accuracy of the camera or cause damage to the sensor.
CAUTION
• Burn Hazard. Reflective materials may have a higher actual temperature
than the measured temperature. Set emissivity to match the object being
measured (see Emissivity section).
SYMBOLS ON TESTER
Warning or Caution
Read Instructions
Conformité Européenne: Conforms with
European Economic Area directives
UKCA - United Kingdom Conformity Assessment
Do not place equipment and its accessories in the trash
FEATURE DETAILS
1. Camera
2. USB-C Connector
3. USB-C to Micro-USB Adapter
4. USB-C Extension
12
FIG. A
3
4
