Manual
Test Device for Peel Tests PCE-PST 1
Version 1.2
Date of creation: 24.06.2015
Date of last change: 04.07.2023
Contents
1 Introduction ............................................................................................................. 3
2 Safety notes ............................................................................................................. 3
3 Specication ............................................................................................................ 4
3.1 Technical specications .............................................................................................................. 4
3.2 Delivery contents ........................................................................................................................ 4
4 System description ................................................................................................. 5
4.1 Composition and components .................................................................................................... 5
4.2 Display ........................................................................................................................................ 5
4.3 Controls ...................................................................................................................................... 6
4.3.1 Force gauge ................................................................................................................................... 6
4.3.2 Test stand 7......................................................................................................................................
4.4 Connectors ................................................................................................................................. 8
4.4.1 Force gauge ................................................................................................................................... 8
4.4.2 Test stand 9......................................................................................................................................
4.5 Memory ....................................................................................................................................... 9
5 Operation ............................................................................................................... 10
5.1 Getting started .......................................................................................................................... 10
5.2 Performing a test ...................................................................................................................... 11
6 Settings .................................................................................................................. 14
6.1 Measurement ............................................................................................................................ 14
6.1.1 Speed ........................................................................................................................................... 14
6.1.2 Unit ............................................................................................................................................... 14
6.1.3 Auto-zeroing ................................................................................................................................. 14
6.1.4 Threshold ..................................................................................................................................... 15
6.1.5 Directi on ....................................................................................................................................... 15
6.1.6 PEAK ............................................................................................................................................ 15
6.2 Memory ..................................................................................................................................... 15
6.2.1 Statistics ....................................................................................................................................... 15
6.2.2 Settings ........................................................................................................................................ 16
6.3 Conguration ............................................................................................................................ 16
6.3.1 Interface ....................................................................................................................................... 16
6.3.2 Calibration .................................................................................................................................... 17
6.3.3 Info ............................................................................................................................................... 17
6.3.4 Time & date .................................................................................................................................. 17
6.3.5 LCD settings ................................................................................................................................. 17
6.3.6 Language ..................................................................................................................................... 17
6.3.7 Printout ......................................................................................................................................... 17
6.3.8 Keyboard ...................................................................................................................................... 17
6.3.9 Auto Power O ............................................................................................................................. 18
6.3.10 Battery .......................................................................................................................................... 18
6.3.11 External input ............................................................................................................................... 18
6.3.12 Firmware update .......................................................................................................................... 18
6.3.13 Defaults ........................................................................................................................................ 18
7 Software ................................................................................................................. 18
8 Contact ................................................................................................................... 20
Manual
3
1 Introduction
Thank you for purchasing a PCE-PST 1 test device for peel tests from PCE Instruments.
The PCE-PST 1 was designed for performing peel tests in a 90 ° angle and for measuring forces up to
500 N. To do so, the PCE-PST 1 comes with PCE-FB 500 force gauge which is mounted a motor-a on
powered slide unit. A claw mechanism, which is attached to the force sensor, grabs and holds the sample
when performing a peel test. To start the test, you just have to press the start button. The slide unit starts
to move and the claw mechanism automatically grabs the end of sample, while two guiding pulleys hold
the rest of the sample in place. The movement of the slide unit now exerts a force on the sample which is
recorded by the force gauge.
The internal memory of the device can store up to 6,400 readings. Additionally, the force gauge also
comes with a slot for micro SD cards and an USB interface for transferring the data to a PC.
2 Safety notes
Please read this manual carefully and completely before you use the device for the rst time. The device
may only be used by qualied personnel and repaired by PCE Instruments personnel. There is no
warranty of damages or injuries caused by non-observance of the manual.
• The device may only be used the approved temperature range. Avoid severe uctuations in in
temperature as well as poor ventilation.
• Do not expose the equipment to water or water vapour. Do not touch it when your hands are wet
to avoid damage of the internal precision components as this item is not waterproof.
• Avoid direct sunlight.
• Do not place the instrument close to a heater or similar equipment.
• Excessive shock and vibration should be avoided.
• Make sure not to expose the device to chemical materials or explosive gases.
• The case should only be opened by qualied personnel of PCE Instruments.
• The instrument should never be placed with the user interface facing an object (e.g. keyboard
side on a table
).
• You must not make any technical changes the device. to
• The device should only be cleaned with a damp cloth / use only -neutral cleaner. However, pH
some parts like the plug and interface cannot be cleaned with a damp cloth.
• Clean the LC display after each use to avoid drying of dirt which can affect the device’s
appearance (scratches etc.) and functionality negatively. Before cleaning, switch o the device.
• If the product emits smoke, sparks, strange noises or odours, please switch it o immediately and
unplug it.
• The device may only be used with PCE accessories or equivalent.
• Make sure you use the proper mains adaptors for the force gauge and the test stand, as they
dier in current. Using the wrong mains adaptor can cause damage to the devices.
This manual is published by PCE Instruments without any guarantee.
We expressly point to our general guarantee terms which can be found in our general terms of business.
If you have any questions please contact PCE Instruments.
