Test Report: PB 450 72N - -
450W High Reliable Ultra Wide Output Range
Intelligent Battery Charger
ļ® DESIGN VERIFY TEST
O F Tutput unction est
Input Function Test
Protection Function Test
C F Tontrol unction est
Component Stress Test
ļ® SAFETY & . E.M.C TEST
Safety Test
E.M.C. Test
ļ® RELIABILITY TEST
ENVIRONMENT TEST
450W
High Reliable Ultra Wide Output Range
Intelligent Batter y Charger
N -PB 450 series
Model: Test Report 2 / 9
ļ® DESIGN VERIFY TEST
OUTPUT FUNCTION TEST
NO T EST ITEM SPECIFICATION TEST CONDITION RESULT
1 BOOST CHARGE VOLTAGE
(default)
72 1.VĀ± 2 V I/P: 230 VAC
O/P:BAT. LOAD
Ta:25ā
7 V 2.6
2 FLOAT CHARGE VOLTAGE
(default)
69 230VĀ± V 0.6 I/P: VAC
O/P:BAT. LOAD
Ta:25ā
6 V 9.6
3 MAX. OUTPUT CURRENT
5.5AĀ± A 0.055 I/P: 230 VAC
O/P: VboostC.V = -4V
Ta:25ā
A 5.53
4
LEAKAGE CURRENT FROM
BATTERY (TYP)
<1mA I/P: AC OFF
O/P:BAT. LOAD
Ta:25ā
mA 0.48
5 OUTPUT CURRENT RANGE
50%~100%Io 230 I/P: VAC
O/P:C.V =84V
Ta:25ā
2.59 A ~5.53
6 MAX. POWER 462W I/P: 230 VAC
O/P:C.V =84V
Ta:25ā
463.4W
INPUT FUNCTION TEST
NO T EST ITEM SPECIFICATION TEST CONDITION RESULT
1 INPUT VOLTAGE RANGE
90 264VAC~ VAC
127VDC~370VDC
(1) I/P:TESTING
O/P:FULL LOAD
(2) I/P:DC TESTING(L:+ N:-)
O/P: FULL LOAD
(3) I/P:DC TESTING(L:- N:+)
O/P: FULL LOAD
Ta:25ā
(1) 8 V~ V 6.4 264
(2) 120Vdc~370Vdc/FULL
LOAD
(3) 120Vdc~370Vdc/FULL
LOAD
I/P:
LOW- - V LINE 3V=87
HIGH- LINE+15%= 300 V
O/P:BAT. LOAD
(PLEASE CHECK D C ERATING URVE)
ON: 30 Sec . OFF: 30 Sec 10MIN
( AC POWER ON/OFF NO DAMAGE )
TEST: OK
2 INPUT FREQUENCY RANGE 47HZ ~63 HZ
NO DAMAGE
I/P: 9 0 VAC ~264 VAC
O/P:FULL~MIN LOAD
Ta:25ā
TEST: OK
3 LEAKAGE CURRE NT
< 0.75 240 mA / 240VAC I/P: VAC
O/P:Min LOAD
Ta:25ā
0.48mA
4 INPUT CURRENT (TYP) A 230 V/ 2.2
115 V/ 4.5A
I/P: 230 VAC
I/P: 115 VAC
I = A2.18 / 230VAC
I = A4.42 / 115VAC
450W
High Reliable Ultra Wide Output Range
Intelligent Batter y Charger
N -PB 450 series
Model: Test Report 3 / 9
O/P:BAT. LOAD
Ta:25ā
5 POWER FACTOR (TYP)
0.95/ 230 VAC
0.98/ 115 VAC
I/P: 230 VAC
I/P: 115 VAC
O/P:BAT. LOAD
Ta:25ā
PF= 90.98 / 230VAC
PF= 80.99 / 115VAC
6 EFFICIENCY 93%(TYP) I/P: 230 VAC
O/P:BAT. LOAD(C.V =84V)
Ta:25ā
9 % 3.6
7 INRUSH CURRENT (TYP) A 230 V/ 50
COLD START
I/P: 230 VAC
O/P:BAT. LOAD
Ta:25ā
I =49.0A/ 230VAC
T50= s/230V1.02m
INPUT=230VAC/50HZ @ FULL LOAD
CH1 : AC Input Voltage CH4 : Input current (1V=1A)
8 GAIN- PHASE MARGIN TEST
1.
GAIN MARGIN < - 10dB
PHASE MARGIN>=60
Gain Curve slope:
- - 10dB/dec~ 40dB/dec
(1) CC )/MODE(Vboost
90% LOAD
/264Vac
(2) CC )/ MODE(Vboost 90% LOAD
/ 90Vac
Ta:25ā
(1) 60.3090 13.203Ā°/ -
dB /
- 29.2 dB/dec
(2) 60.5110 13.005 -Ā°/
dB /
- 22.4 dB/dec
PROTECTION FUNCTION TEST
NO T EST ITEM SPECIFICATION TEST CONDITION RESULT
1
OVER VOLTAGE PROTECTION
CH1:102 12V~ 0V
PROTECTION RESULT
Shut down and latch off o/p
voltage, re-
power on to
recover.
I/P: 264 VAC
I/P: 90 VAC
O/P:TESTING
Ta:25ā
112.0/ 264VAC
11 2.0V/ 90VAC
PROTECTION TYPEļ¼
Shut down and latch off o/p
voltage, re-
power on to
recover.
2 OVER TEMPERATURE
PROTECTION
SPEC:
NO DAMAGE
Shut down o/p voltage,
recover automatically after
temperature goes on.
I/P: 264 VAC
I/P: 90 VAC
O/P:BAT. LOAD
O.T.P. Active
PROTECTION TYPEļ¼ OK
Shut down o/p voltage,
recover automatically after
temperature goes on.
3 SHORT PROTECTION
SHORT EVERY OUTPUT
1 HOUR NO DAMAGE
4.9 .55A~11 A
Constant current
I/P: 264 VAC
O/P: BAT. LOAD
Ta:25ā
NO DAMAGE
A 8.12
PRO TECTION TYPEļ¼
Constant current
