Page 1/9
Test Report: PB 1200N - -48
W 1200 High Reliable Ultra Wide Output Range
Intelligent Battery Charger
ļ® DESIGN VERIFY TEST
O F Tutput unction est
Input Function Test
Protection Function Test
C F Tontrol unction est
Component Stress Test
ļ® SAFETY & . E.M.C TEST
Safety Test
E.M.C. Test
ļ® RELIABILITY TEST
ENVIRONMENT TEST
1200W High Reliable
Ultra Wide Output Range
Intelligent Battery Charger
N -PB 1200 series
Model: Test Report 2 / 9
ļ® DESIGN VERIFY TEST
OUTPUT FUNCTION TEST
NO T EST ITEM SPECIFICATION TEST CONDITION RESULT
1 BOOST CHARGE VOLTAGE
ļ¼ ļ¼default
57.6 48VĀ± 0. V I/P: 230 VAC
O/P:BAT. LOAD
Ta:25ā
57.7V
2 FLOAT CHARGE VOLTAGE
ļ¼ ļ¼default
55.2 48VĀ± 0. V I/P: 230 VAC
O/P:BAT. LOAD
Ta:25ā
55.41 V
3 MAX. OUTPUT CURRENT AĀ± A 18 0.18 I/P: 230 VAC
O/P: BAT. LOAD
Ta:25ā
1 A 7.94
4
LEAKAGE CURRENT FROM
BATTERY (TYP)
<1mA I/P: AC OFF
O/P:BAT. LOAD
Ta:25ā
0.255mA
5 OUTPUT CURRENT RANGE
50%~100%Io 230 I/P: VAC
O/P:C = V V 67.2
Ta:25ā
8.47A 18.005~ A
5 MAX. POWER 1209.6W I/P: 230 VAC
O/P:C.V =67.2V
Ta:25ā
1 W 210.4
INPUT FUNCTION TEST
NO T EST ITEM SPECIFICATION TEST CONDITION RESULT
1 INPUT VOLTAGE RANGE
90 264VAC~ VAC
127VDC~370VDC
(1) I/P:TESTING
O/P:FULL LOAD
(2) I/P:DC TESTING(L:+ N:-)
O/P: 80% LOAD
(3) I/P:DC TESTING(L:- N:+)
O/P: FULL LOAD
Ta:25ā
(1) 264 80% 84.7V~ V/ LOAD
176.6 264V~ V/ FULL LOAD
(2) 119Vdc~370Vdc/80% LOAD
(3) 160Vdc~370Vdc/FULL LOAD
I/P:
LOW- - V LINE 3V=87
HIGH- LINE+15%= 300 V
O/P:BAT. LOAD
(PLEASE CHECK D
ERATING
C URVE)
ON: 30 Sec . OFF: 30 Sec 10M IN
( AC POWER ON/OFF NO
DAMAGE )
TEST: OK
2 INPUT FREQUENCY RANGE 47HZ ~63 HZ
NO DAMAGE
I/P: 9 0 VAC ~264 VAC
O/P:FULL~MIN LOAD
Ta:25ā
TEST: OK
3 LEAKAGE CURRENT 1 < mA / 240VAC I/P: 240 VAC
O/P:Min LOAD
Ta:25ā
0.192mA
1200W High Reliable
Ultra Wide Output Range
Intelligent Battery Charger
N -PB 1200 series
Model: Test Report 3 / 9
4 INPUT CURRENT (TYP) A 230 V/6.5
115 V/ 12A
I/P: 230 VAC
I/P: 115 VAC
O/P:BAT. LOAD
Ta:25ā
I = 5.59A/ 230VAC
I = 9.96A/ 115VAC
5 POWER FACTOR (TYP) 0.95 230 / VAC
0.98/ 115 VAC
I/P: 230 VAC
I/P: 115 VAC
O/P:BAT. LOAD
Ta:25ā
PF= 0.985 / 230VAC
PF= 0.995 / 115VAC
6 EFFICIENCY 94%(TYP) I/P: 230 VAC
O/P: C = V BAT. LOAD ļ¼V 67.2 ļ¼
Ta:25ā
94.5%
7 INRUSH CURRENT (TYP) A 230 V/ 50
COLD START
I/P: 230 VAC
O/P:BAT. LOAD
Ta:25ā
I = 47.6A/ 230VAC
T50= 2.14 ms/230V
INPUT=230VAC/50HZ @ FULL LOAD
CH1 : AC Input Voltage CH4 : Input current (1V=1A)
8 GAIN- PHASE MARGIN TEST
GAIN MARGIN < - 10dB
PHASE MARGIN>=60
Gain Curve slope:
- - 10dB/dec~ 40dB/dec
(1) /264Vac )CV MODE(Vboost
(2) )/90 CV MODE(Vboost Vac
(1)110.62 18.665 11.6Ā°/- dB/- dB/dec
(2)107.03 19.452 11.1Ā°/- dB/- dB/dec
PROTECTION FUNCTION TEST
NO T EST ITEM SPECIFICATION TEST CONDITION RESULT
1
OVER VOLTAGE PROTECTION
CH1:82V~100V
PROTECTION RESULT
Shut down and latch off o/p
voltage, re-
power on to
recover.
I/P: 264 VAC
I/P: 90 VAC
O/P:TESTING
Ta:25ā
93.0V/ 264VAC
9 3.0 V/ 90VAC
PROTECTION TYPEļ¼
Shut down and latch off o/p
voltage, re-
power on to
recover.
2 OVER TEMPERATURE
PROTECTION
SPEC:
NO DAMAGE
Shut down o/p voltage,
recover automatically after
temperature goes down.
I/P: 264 VAC
I/P: 90 VAC
O/P:BAT. LOAD
O.T.P. Active
PROTECTION TYPEļ¼OK
Shut down o/p voltage,
recover automatically after
temperature goes down.
3 SHORT PROTECTION
SHORT EVERY OUTPUT
1 HOUR NO DAMAGE
Constant current Rangeļ¼
I/P: 264 VAC
O/P: BAT. LOAD
Ta:25ā
NO DAMAGE
Constant current Rangeļ¼
17.86 A
