Page 1/4
Owner’s
Manual
Video Tripod
VT-4000
Tilt/Pan
Bar
Retractable
Ground Spikes Mid-Level
Spreader
Ball Level
Locking Knob
Mounting Plate
Bubble
Level
Locking Knob
Tilt/Pan Bar
Mount
Mounting Plate
Capture Release
Tilt Lock
Knob
Pan Lock
Knob
Leg
Flip-Lock
Magnus offers a spare or replacement quick-release
plate for the VT-4000 tripod head. Having a quick-
release plate attached to the camera’s base at all
times allows you to attach or remove the camera
from the tripod without having to waste time
fumbling with the threaded mount. Your VT-4000
Tripod includes one quick-release plate, but you may
want to have spares for other cameras. The Magnus
VT-QRP400 has a 1/4˝-20 mounting stud and a
retractable register pin for correct camera positioning.
The anti-skid mounting surface stabilizes the camera.
ONE (1) YEAR LIMITED WARRANTY
Magnus provides a limited warranty that this product is free from defects in materials and
workmanship to the original purchaser under normal use for a period of one (1) years
from the original purchase date Or thirty (30) days after replacement whichever occurs
later. Magnus’ responsibility with respect to this limited warranty shall be limited solely to
repair or replacement, at its option, of any product which fails during normal consumer
use. This warranty does not extend to damage or failure which results from misuse,
neglect, accident, alteration, abuse, improper installation or maintenance. To obtain a
replacement during the time of this warranty, please return the defective item with proof
of purchase along with an RMA number to the place of purchase. This warranty gives you
specific legal rights, and you may also have other rights which vary from state to state.
www.SupportsByMagnus.com
To adjust
locking lever
tension, use
the supplied
allen wrench.
To tighten, with
the lock in a
closed position,
turn the
adjustment screw (clockwise) ¼ turn at a
time until desired locking tension is reached.
To loosen turn the adjustment screw (counter
clockwise)
¼ turn at a time until desired locking tension
is reached.
Caution:
Do not over tighten the adjustment screw as
this may cause improper operation.
Locking Knob
Flip-Lock Adjustment
Quick-Release Plate for VT-4000 Tripod
Product Specifications
| Brand: | Magnus |
| Category: | Tripod |
| Model: | VT-4000 |
