Page 1/8
Two-Stage Video Tripod
with Fluid Head
VT-5000
5000H/TL750A
Owner’s
Manual
Thank you for choosing Magnus.
The Magnus REX VT-5000 tripod is designed with
advanced features that professional videographers
and cinematographers need for their camera-support
systems and shooting styles. It’s constructed with
sturdy, high-grade aluminum legs with flip locks
that provide stable support in the most demanding
environments. The video head delivers secure
positioning and smooth camera movement with fixed
pan and fluid drag adjustment controls.
• Please read and follow these instructions, and keep this
manual in a safe place.
• Never set up or pull down a tripod while a camera is
mounted.
• Do not move the tripod or adjust the legs while a camera
is mounted.
• Do not exceed the maximum weight capacity of the
tripod.
• Never leave a camera unattended on the tripod.
• The camera should be securely fastened to the quick-
release plate before mounting onto the tripod.
• Never mount a camera to the tripod until all tripod legs
are locked and stabilized.
• Do not stand on, rest on, or hang anything from the
mid-level spreader.
• Do not lift or move the tripod by the head.
• Keep hands clear of the inside of the legs, to avoid
trapping fingers.
• Safe operation of the tripod is the user’s responsibility.
• All images are for illustrative purposes only.
Precautions
Speci
Specifications
Legs
Material: Anodized aluminum alloy
Head Attachment Fitting: 75 mm bowl
Leg Stages / Sections: Two stage
Leg Lock Type: Flip lock
Independent Leg Spread: Yes
Spreader: Mid level (adjustable)
Spiked / Retractable Feet: Nonretractable spikes with
removable nonslip rubber feet
General
Load Capacity: 17 lb. (7.7 kg)
Maximum Working Height: 64.25 in. (163.2 cm)
Minimum Working Height: 29 in. (73.6 cm)
Folded Length: 32.6 in. (82.8 cm)
Weight: 11.2 lb. (5.1 kg)
Materials: Anodized aluminum alloy
Bubble Level: Yes
Head
Counterbalance System: Spring loaded
Quick-Release Plate: 4.7 × 2 × 0.4 in. (12 × 5 × 1 cm)
Quick-Release Safety: Yes
Camera Mounting Screw: 1/4”-20, 3/8”-16
Built-In Balance Plate: Yes
Tilt Drag: Adjustable, fluid
Tilt Range: +70°/-80°
Tilt Lock: Yes
Pan Drag: Fixed, fluid
Pan Range: 360°
Pan Lock: Yes
Pan-Handle Rosettes: 2 (left and right)
Leveling Bubble / Illuminated: Yes, unilluminated
Head Mount Type: 75 mm half ball
Product Specifications
| Brand: | Magnus |
| Category: | Tripod |
| Model: | REX VT-5000 |
