Page 1/6
Owner’s
Manual
Photo Tripod
DX Series
Photo Tripod Components
Thank you for choosing Magnus.
Congratulations on the purchase of your new
Magnus tripod. This tripod features an adjustable
center column for smooth and precise camera height
adjustment, and telescoping legs with flip-locks
for fast and easy leg adjustments. The three-way
pan & tilt head gives you total control over camera
positioning, and the quick-release plate features a
1/4”-20 male thread for universal camera mounting.
There is also a bubble level to ensure that your shot is
properly aligned.
Please read and follow these instructions, and keep
this manual in a safe place.
Platform Orientation
Locking Knob
Universal ¼-20
Mounting Screw
Tilt/Pan Bar /
Tilt Lock
Height
Extender Crank
Center Column
Locking Collar
Weight
Hook
Quick-Release
Mounting Plate
Pan Locking
Knob
Leg
Flip-Lock
Image is for illustration purposes only.
Features varies by model
Center Brace
Locking Collar
Foam Padding
Retractable
Spiked Feet
(On Select Models)
Opening the Tripod
1 Always extend the legs from the top flip-locks first.
Pull out on each flip-lock and extend the legs to the
desired height. Relock each leg (Fig. A-B)
2 Rotate the locking
collar counterclockwise
to release the center
brace, and gently pull
the legs out. Push
down on the center
brace, and then rotate
the locking collar
clockwise to lock the
legs in place (Fig. C)
Mounting the Quick-Release Plate to
the Camera
1 To remove the quick-
release plate from the
tripod head, pull and
hold the plate locking
lever and remove the
quick-release plate
(Fig. D)
2 Line up the quick-
release plate
lengthwise with
the bottom of the
camera. Match the
quick-release plate
screw to the camera’s
mounting thread, and
mount the plate to the
camera by rotating
the screw clockwise
until snug (Fig. E)
Figure A Figure B
Figure E
Figure D
Figure C
Product Specifications
| Brand: | Magnus |
| Category: | Tripod |
| Model: | DX-5330 |
