Page 1/17
P/N: 2900-301615 Rev 1 www.kramer .comav
USER MANUAL
MODELS:
EXT3-XR- TR
EXT3-TR
4K60 HDMI/USB Extender
Kramer Electronics Ltd.
EXT3- - Contents XR TR –
i
Contents
Introduction 1
Getting Started 1
Overview 2
Typical Applications 3
Dening EXT3- -TR and EXT3- 4XR TR
Mounting EXT3- - 6XR TR
Connecting the 4K60 HDMI/USB Extender 7
Connecting EXT3- -TR and EXT3- 8XR TR
Connecting to EXT3- -TR via RS-232 XR 10
Wiring RJ 45 Connectors -10
Setting the DIP-Switches 10
Technical Specications 12
EXT3- -TR Specications XR 12
EXT3-TR Specications 13
Kramer Electronics Ltd.
EXT3- - EXT3- Introduction XR TR, TR –
1
Introduction
Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been providing a world
of unique, creative, and aordable solutions to the vast range of problems that confront the
video, audio, presentation, and broadcasting professional on a daily basis. In recent years, we
have redesigned and upgraded most of our line, making the best even better!
Getting Started
We recommend that you:
• Unpack the equipment carefully and save the original box and packaging materials for
possible future shipment.
• Review the contents of this user manual.
Go to www.kramerav.com/downloads/EXT3- - www.kramerav.com/downloads/TP-XR TR or
600TR to check for up- -date user manuals, application programs, and to check if to
rmware upgrades are available (where appropriate).
Achieving Best Performance
• Use only good quality connection cables (we recommend Kramer high-performance,
high-resolution cables) to avoid interference, deterioration in signal quality due to poor
matching, and elevated noise levels (often associated with low quality cables).
• Do not secure the cables in tight bundles or roll the slack into tight coils.
• Avoid interference from neighboring electrical appliances that may adversely inuence
signal quality.
• Position your Kramer EXT3- -XR TR away from moisture, excessive sunlight / EXT3-TR
and dust.
Safety Instructions
Caution:
• This equipment is to be used only inside a building. It may only be connected to other
equipment that is installed inside a building.
• For products with relay terminals and GPI\O ports, please refer to the permitted rating
for an external connection, located next to the terminal or in the User Manual.
• There are no operator serviceable parts inside the unit.
Warning:
• Use only the power cord that is supplied with the unit.
• To ensure continuous risk protection, replace fuses only according to the rating
specied on the product label which located on the bottom of the unit.is
Product Specifications
| Brand: | Kramer |
| Category: | AV extender |
| Model: | EXT3-TR |
