Page 1/4
AOU-112N
540TVL, IR Bullet Camera
Quick Start Guide
2
GVI Security
I. Precautions
Do not attempt to disassemble the camera. To prevent electric shock, do not remove the screws or covers.
There are no user serviceable parts inside the camera. Refer to qualified service personnel for servicing the
camera and camera accessories.
Do not use strong solvents or detergents to clean the camera. Wipe the camera with a dry cloth. Use a mild
detergent on the outside of the camera and wipe it gently if the camera is dirty.
Prior to operating the camera, check the temperature, humidity, and power source ratings. Use the camera
under conditions where the temperature is between 14˚F ~ 122˚F (-10˚C ~ 50˚C).
Avoid facing the camera into direct sunlight. Do not aim the camera at bright objects. Never face the camera
into direct sunlight or other extremely bright objects; otherwise, blooming or smearing may occur.
Handle the camera with care. Do not abuse the camera. Avoid striking, shaking, dropping, or other blunt
force. The camera may be damaged by improper handling or storage.
Do not expose the camera to a room or area filled with cigarette smoke, heavy dust, or gas.
2. Composition
Confirm that the following parts are included in the camera package.
3. Features
• Bullet IR camera
• 1/3” Super HAD Sony CCD
• 540 TV Lines Resolution
• Minimum Scene Illumination 0.1 Lux
• Color & B/W Auto switchable by Photocell and Sensitivity
• Vari-Focal Aspherical DC Auto Iris 3.8~9.5mm F1.2 Lens Built-in
• 30 IR LED with CDS Photocell Auto Switch
• CDS Photocell Auto Switching IR-LED Control 30pcs LEDs(On: 3Lux / Off: 15Lux)
• Weather Resistant (IP66)
• DC12V
3
GVI Security
4. Installation
Notes
Do not disassemble the camera.
1. Always handle the camera with care. Please avoid mechanical shock or vibration, and take
caution to prevent damages or make scratches on the camera window glass due to careless
storage and/or handling.
2. Do not clean the camera body with strong abrasives or soaps. When the camera becomes dirty,
clean it with dry rugs. Take precaution to use dedicated rugs to clean window glass.
3. Please keep the camera in a cool area that is not exposed to the direct sunlight. Failing to do so
can cause undesired effects on the product.
Camera Installation
1. Attach the bracket to the mounting surface by drilling with the supplied screws.
2. Remove the protective sheet from the camera window.
