Wimberley M-2 Manual

Read below 📖 the manual in Italian for Wimberley M-2 (2 pages) in the Not categorized category. This guide has been helpful for 6 people and has been rated 4.5 stars on average by 2 users

Page 1/2
Wimberley, Inc. Phone: 1- - - 434 529 8385
1750 Broadway St Toll Free: 1---888 665 2746 (USA & Canada)
Charlottesville, VA
22902 USA www.tripodhead.com info@tripodhead.com
5 Year Warranty – for details see www.tripodhead.com/warranty.cfm
Instructions on reverse >>
Wimberley, Inc. ©2017, All Rights Reserved Rev. 170707
M 2-
M 2 Upright-
Weight: 3.3 oz
Dimensions (Overall L x W x H): 8.6 x 0.9 X 1.25 in
Materials: Anodized 6061 Aluminum, stainless steel fasteners
Package Contents:
• M 2 Module: -Upright (Qty 1)
Upright Flash Bracket
Module
Made in USA
Thank you for your interest in Wimberley products. If you have any questions or comments please feel free to contact us.
Connecting Flash Bracket Modules:
(The figure below shows the connection between M 3 and upright module; the same principle applies for other module connections.)-
knob
cylindrical nub
Unscrew the knob so that
the upright module can fit
between the cylindrical
nub and the knob base
Forked end of
module
Slip the forked end of the
module over the exposed
threads. Locate one of the
enlarged areas in the forked
end over the cylindrical nub.
Tighten the knob
securely.
Tip: if you find the metal knobs difficult
to grip, try wrapping several layers of
self fusing rubber grip tape (-3M 2155)
around the knob to cushion it and make it
easier to grip in the field.
About the M-2:
The M 2 Upright - is one of the components of the Wimberley Modular Flash Bracket System. It is
included in the F 1 combo unit.-
