Page 1/36
Alpha Series Indoor
WDR Dome Cameras
• 650 TV Lines of Resolution
• 1/3” Sony SuperHAD II CCD
• Hercules II DSP Engine
• 3.6mm Fixed and 2.8~12mm IR Corrected
DC Auto-Iris Lens Options
• Available with 35 IR LEDs (120’ Range)
• Advanced OSD Functions: WDR, 3D DNR,
DSS, DIS, Sens-up, Motion Detection, Privacy
• Secondary Video Output (Cable Included)
• 3-Axis Mount for Optimum Viewing Angle
VITEK
TABLE OF CONTENTS
BOX CONTENTS / MOUNTING ACCESSORIES 2
AVAILABLE MODELS 3
VTD-A4F/I INSTALLATION 4
VTD-A2812/I INSTALLATION 5
VTD-AR2812/I INSTALLATION 6
INSTALLATION TIPS 7
OSD OPERATION 8-27
DIMENSIONS 28
SPECIFICATIONS 29-31
1
1) Alpha Dome Camera
2) Mounting Accessories
3) Secondary Video Output Cable
4) This instruction Manual & Mounting Template
Self Tapping Screws
For attaching the housing base to a
solid surface.
Type #: Phillips ST4x30
Qty: 4 (2 screws - VTD-A4F/I)
Secondary Video Output Cable
To be used with a service monitor for
adjusting
the angle, focus and zoom.
Qty: 1
BOX CONTENTS
MOUNTING ACCESSORIES
2
