Page 1/24
VITEK
VTC-IRH70/650
Long Range Weatherproof IR
Bullet Camera
1/3” Super HAD Color CCD
High Resolution with 560 TV Lines Resolution in Color (600 TV Lines in B/W mode)
70 IR LEDs at 850nm enable viewing in Total Darkness up to 300 Feet
Simultaneous Color and Black & White Focus Adjustment
Infrared LED Dynamic Intensity Control with automatic brightness adjustment of IR LEDs
to help prevent washed out images when objects are too close
Camera and IR LED compartments are separated using a dual glass design to prevent
stray IR light from entering the lens
Vari-Focal 6~50mm DC Auto Iris IR Lens
Virtual Wide Dynamic Range
OSD control
Secondary Video Output & OSD Control Joystick are accessible inside a gasket sealed
removable side panel
Externally adjustable Focus & Zoom with clutch mechanism to eliminate over-tightening
Gasket sealed external focus and zoom controls with clutch mechanism to eliminate
over-tightening for ease of installation and adjustment
Heavy Duty IP68 rated Weather/Vandal Resistant Aluminum Construction is 100% water
and dust proof
Fully adjustable 3 axis wire feed-through mount
Dual Voltage: 12VDC / 24VAC
VTC-IRH70-650 
1
Table of contents
1. Safety Instructions and Notes.................................................................................. 2
2. General Descriptions ............................................................................................... 3
3. Supplied Items ......................................................................................................... 3
4. Part names .............................................................................................................. 4
5. Installation Instructions ............................................................................................ 5
5.1. Mounting The Camera......................................................................... 5
5.2. Power Supply Connections.................................................................. 5
5.3. Setup of Zoom and Focus ................................................................... 5
6. Setup Menu ............................................................................................................. 6
6.1 Main Menu........................................................................................... 6
6.2 Exposure Menu ................................................................................... 7
6.2.1 BLC Menu ........................................................................................... 8
6.2.2 HSBLC Menu ...................................................................................... 9
6.2.3 D-WDR Menu ..................................................................................... 10
6.3 Day Night Menu.................................................................................. 10
6.3.1 Day Night Auto Menu ......................................................................... 10
6.4 3-DNR Menu ...................................................................................... 12
6.5 Picture Menu ...................................................................................... 13
6.6 Special Menu...................................................................................... 14
6.6.1 Camera Title Menu ............................................................................. 15
6.6.2 Motion Menu....................................................................................... 16
6.6.3 Privacy Me ...................................................................................... 17 nu
6.7. Lens Menu.......................................................................................... 18
6.7.1 Focus Adjust Menu............................................................................. 18
7. Specifications.......................................................................................................... 19
8. Dimensional Drawings ............................................................................................ 20
9. Warranty ................................................................................................................. 21
       VTC-IRH70-650
2
The symbol is intended to alert the user to the presence of important
operating and maintenance(servicing) instructions in the literature
accompanying the unit.
The symbol is intended to alert the user to the presence of
un- insulated "dangerous voltage" within the product's enclosure that
may be of sufficient magnitude to constitute a risk of electric shock.
Warning(NTSC version) -- This equipment has been tested and found to comply with the limits for a Class
A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference when the equipment is operated in a commercial environment. This
equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful interference in which case the
user will be required to correct the interference at his own expense./her
Caution -- roved by Any changes or modifications in construction of this device which are not expressly app
the party responsible for compliance could void the user's authority to operate the equipment.
1. Safety Instructions and Notes
• Please read these safety and operating instructions before placing the camera into
operation.
Keep the manual in a safe place for later reference.
Pay attention to safety when laying the connection cable and observe that the
cable is not subjected to
heavy loads, kinks, damage or moisture.
Never open the device to expose boards or lens.
The warranty becomes void if repairs are undertaken by unauthorized persons.
Maintenance and repair must be carried out only by authorized service centers.
Use only a mild detergent to clean the housing.
Keep the window surface clean from dirt or dust, which may reflect the infrared
light into the lens at night..
• The camera should never be operated the technical specifications as thin an environment that exceeds is
may result in the destruction actory warranty of the product and will also void the f .
WARNING
Caution
To prevent electric shock
and risk of fire hazards, do
NOT use other than
specified power source.
