INSTRUCTION MANUAL
ESS SERIES BATTERY PACK
IN CASE OF ANY QUERY/ISSUE WITH THE PRODUCT, PLEASE REACH OUT TO US AT: SUPPORT@V-TAC.EU
FOR MORE PRODUCTS RANGE, INQUIRY PLEASE CONTACT OUR DISTRIBUTOR OR NEAREST
DEALERS. V-TAC EUROPE LTD. BULGARIA, PLOVDIV 4000, BUL.L.KARAVELOW 9B
Thank you for selecting and buying V-TAC Product. V-TAC will serve you
the best. Please read these instructions carefully & keep this user manual
handy for future reference. If you have any another query, please contact
our dealer or local vendor from whom you have purchased the product.
They are trained and ready to serve you at the best.
INTRODUCTION
Multi-Language Manual QR CODE
Please scan the QR code to access the manual
in multiple languages.
About This Document
Intended Audience
This document is intended for:
Hardware installation engineers
Technical support engineers
Maintenance engineers
Users
Symbol Conventions
The symbols that may be found in this document are defined as follows.
Symbol Definition Remarks
Danger
Indicates a hazard with a high level of risk which, if not avoided, will
result in death or serious injury.
Warning
Indicates a hazard with a medium level of risk which, if not avoided,
could result in death or serious injury.
Attention Indicates a hazard with a low level of risk which, if not avoided,
could result in minor or moderate injury.
Note
Supplements the important information in the main text.
NOTE is used to address information not related to personal injury,
equipment damage, and environmental deterioration.
2 Overview
2.1 Product Application
RESS is a next-generation product developed by V-TAC, which is used in residential energy storage solut
ions. This battery system has a capacity of 19.2 kWh or 20.48 kWh.
RESS integrates the high-performance BMS. To extend battery life, it has multiple protection functions
such as system over-charge, system over-discharge, cell over-voltage, cell under-voltage, charging over-
current, discharging over-current, and insulation fault. It also has RS485, CAN, and dry contact
communication, allowing for remote monitoring.
2.2 Product Composition
The RESS consists of one battery cabinet (two battery boxes and one chassis base inside), one high-
voltage box, and four battery modules.
The composition of the RESS is shown as follows:
Figure 1. RESS composition
(1) High-voltage box (2) Battery module (3) Battery cabinet
