Page 1/50
R
INSTRUCTION MANUAL
SOLAR HYBRID INVERTER
INTRODUCTION
USER MANUAL QR CODE
: SUN-8K-SG01LP1-EU
IN CASE OF ANY QUERY/ISSUE WITH THE PRODUCT, PLEASE REACH OUT TO US AT: SUPPORT@V-TAC.EU
FOR MORE PRODUCTS RANGE, INQUIRY PLEASE CONTACT OUR DISTRIBUTOR OR NEAREST
DEALERS. V-TAC EUROPE LTD. BULGARIA, PLOVDIV 4000, BUL.L.KARAVELOW 9B
MODEL
: 11803SKU
Thank you for selecting and buying V-TAC Product. V-TAC will serve you the
best. Please read these instructions carefully & keep this user manual handy
for future reference. If you have any another query, please contact our dealer
or local vendor from whom you have purchased the product. They are
trained and ready to serve you at the best.
Please scan the QR code to access the
manual in multiple languages.
WARNING
1. Safety Introductions
2. Produc Introduction
1. Please make sure to turn off the power before starting the installation.
2. Installation must be performed by a qualifi ed electrician.
This marking indicates that this
product should not be disposed of
with other household wastes.
Caution, risk of electric shock.
• This chapter contains important safety and operating instructions. Read and keep this manual
for future reference.
• Before using the inverter, please read the instructions and warning signs of the battery and
corresponding sections in the instruction manual.
• Do not disassemble the inverter. If you need maintenance or repair, take it to a professional
service center.
• Improper reassembly may result in electric shock or fire.
• To reduce risk of electric shock, disconnect all wires before attempting any maintenance or
cleaning. Turning off the unit will not reduce this risk.
• Caution: Only qualified personnel can install this device with battery.
• Never charge a frozen battery.
• For optimum operation of this inverter, please follow required specification to select appropriate
cable size. It is very important to correctly operate this inverter.
• Be very cautious when working with metal tools on or around batteries. Dropping a tool may
cause a spark or short circuit in batteries or other electrical parts, even cause an explosion.
• Please strictly follow installation procedure when you want to disconnect AC or DC terminals.
Please refer to " Installation" section of this manual for the details.
• Grounding instructions - this inverter should be connected to a permanent grounded wiring
system. Be sure to comply with local requirements and regulation to install this inverter.
• Never cause AC output and DC input short circuited. Do not connect to the mains when DC
input short circuits.
This is a multifunctional inverter, combining functions of inverter, solar charger and battery
charger to offer uninterruptible power support with portable size. Its comprehensive LCD display
offers user configurable and easy accessible button operation such as battery charging,
AC/solar charging, and acceptable input voltage based on different applications.
2.1 Product Overview
1: Inverter Indicators
2: LCD display
3: Function Buttons
4: DC Switch
5: Power on/o button
6: RS 485 port
7: CAN Port
8: Battery input connectors
9: Function Port
10: Meter_CON port
11: Parallel port
12: PV input with two MPPT
13: Grid
14: Generator input
15: Load
16: WiFi Interface
1
2
3
4
5
8
9
10
11
12
13
14
15
16
7
6
