Page 1/2
BigAmp Pi
ë
zo
High-end in-line
instrument preamp
USER GUIDE
©
BigAmp Piëzo
GENERAL DESCRIPTION
Philosophy BigAmp Piëzo is a small sized high
quality jfet instrument preamp which performs equally well
on stage as it does in a studio environment. It is specially
designed for piëzo transducers and has a 7.5 Mega Ohms
input Impedance, which enables the transducer to deliver
its full potential. Signal amplification is low (3dB) to allow
for the highest possible headroom. Because of its small
size BigAmp piëzo can be connected as close to the
transducer as possible which keeps cable capacitance to a
minimum.
Operation Stick BigAmp Piëzo on an XLR cable, plug in your
electric guitar, Bass (or any other instrument with a pi zo transducer) ë
and switch on Phantom Power. BigAmp Piëzo goes directly into a
balanced input of a preamp or interface.
To achieve the best sonic result it is advised to use a
short TRS/Jack cable between BigAmp Piëzo and your
instrument.
USER GUIDE
Circuit topology BigAmp Piëzo utilises a low noise
jFet amplifier circuit, followed by a low impedance, balanced
buffer which reveals every detail with pinpoint accuracy and
offers high-end sound quality.
Features
Low noise Class A JFet amplifier
3dB amplification
Balanced xlr output
Lots of headroom
freq. response 10hz-100khz (+/- 1dB)
Z-in 7.5MOhm
48V phantom power
Dimensions
height: 3.75’/85mm
width: 0,86’/22mm

Product Specifications

Brand: Triton
Category: Not categorized
Model: BigAmp Piëzo
