Page 1/4
www.sven.fi
USER’S MANUAL
External Card Reader
ac-116
ENG
1
User’s Manual
ac-116
a
c d e f
h
b
g
Fig. 1. Card reader constraction
COPYRIGHT
© 2014. SVEN PTE. LTD. Version 1.0 (V 1.0).
This Мanual and information contained in it are copyrighted. All rights
reserved.
USAGE
Sven AC-116 card reader is designed for reading/writing memory cards.
SAFETY PRECAUTIONS
• Do not disconnect the device while reading/writing a memory card to avoid
data loss.
• Insert a memory card into the slot according to the table below. Use one
memory card at a time only!
SPECIAL FEATURES
• Compatible with USB connectors supporting Plug & Play technology
• Supports most modern memory cards: CF, MD, SD, MMC, RS-MMC, SM,
XD, MS, MS PRO, MS Duo, MS PRO Duo, etc.
SYSTEM REQUIREMENTS
• Available USB 1.1 or 2.0 port
• OS Windows XP/Vista/7/8, Mac
system B10.1x, B10.2x or up,
Linux 2.4.x or up
DESCRIPTION
a LED
b Mini USB port
c SD/MMC slot
d MS slot
e Micro SD slot
f M2 slot
g CF/MD slot
h XD slot
ENG
2
External Card Reader
Technical support is on www.sven.fi
M2
Micro SD, T-FLASH
XD, XD H Type, XD M TYPE
CF I/II, CF Ultra I, CF Extreme, CF Extreme III, MD
SD, SDHC, Extreme SD, Extreme III SD, Ultra II SD,
MMCI, MMCII, MMC 4.0, Ultra MMC
MS, MS Pro, MS Duo, MS Pro Duo, Extreme MS Pro,
Extreme III MS Pro, HS MS MG Pro Duo, MS MagicGate,
MS MG Pro, MS MG Duo, MS MG Pro Duo, MS ROM, HS
MS, MG Pro, Ultra II MS
Slots
M2 Slot
Micro SD Slot
XD Slot
CF Slot
SD Slot
MS Slot
Memory cards supported
MEMORY CARD INSTALLATION TABLE
OPERATION MODE LED
• If the device is connected to a USB port and the memory card is inserted
into the slot correctly, Access LED will light up. a
• During reading/writing Access LED ashes.fl
PACKAGE CONTENTS
• Card reader – 1 рс
• USB cable – 1 рс
• User’s manual – 1 рс
• Warranty card – 1 рс
TROUBLESHOOTING
• If the device does not operate after its connection to a USB port, make
sure the memory card is inserted into the slot correctly.
Product Specifications
| Brand: | Sven |
| Category: | Memory card reader |
| Model: | AC-116 |
