Page 1/4
www.sven.fi
USER’S MANUAL
External Card Reader
AC-110
Front view
Back view
a
a
h
g
f be d c
Thank you for purchasing SVEN PC card reader!
USAGE
Sven AC-110 external card reader is designed for reading/writing memory
cards.
SAFETY PRECAUSIONS
• Do not disconnect the device while reading/writing a memory card to avoid
data loss.
• Insert a memory card into the slot according to the table below. Use one
memory card at a time only!
SPECIAL FEATURES
• Compatible with USB connectors supporting Plug & Play technology
• Supports most modern memory cards: MS/MSPRO, SD/MMC, TF, M2,
XD, CF, etc.
SYSTEM REQUIREMENTS
• Available USB 1.1 or 2.0 port
• OS Windows XP/Vista/7, Mac
system B10.1x, B10.2x or up,
Linux 2.4.x or up
DESCRIPTION
a ACCESS: LED
b Micro SD Slot
c XD Slot
d M2 Slot
e MS Slot
f SD Slot
g CF Slot
h Mini USB port
ENG
1
User’s Manual
ac-110
ENG
2
External Card Reader
Technical support is on www.sven.fi
MEMORY CARD INSTALLATION TABLE
Slot
M2 Slot
MS Slot
CF Slot
SD Slot
Micro SD
XD Slot
Memory cards supported
M2
MS, MS-DUO, MS Pro, MS PRO-Duo, MS MagicGate,
MS Pro MagicGate, MS-Duo MagicGate, MS Pro-DUO
MagicGate, etc.
CF I/II, CF Ultra II, CF Extreme III, Micro Drive, Magicstor
SD, miniSD, MMC-I, MMC-II, MMC4.0, MMC Dual Voltage,
RS-MMC, RS-MMC Dual Voltage, RS-MMC 4.0.
Micro SD
XD
OPERATION MODE LED
• If the device is connected to a USB port and the memory card is inserted
into the slot correctly, Access LED will light up. a
• During reading/writing Access LED ashes.afl
PACKAGE CONTENTS
• Card reader – 1 рс
• PC connection cable – 1 рс
• User’s manual — 1 рс
• Warranty card — 1 рс
TROUBLE SHOOTING
• If the device does not operate after its connection to a USB port, make
sure the memory card is inserted into the slot correctly.
Product Specifications
| Brand: | Sven |
| Category: | Memory card reader |
| Model: | AC-110 |
