Page 1/2
N292501/01
N
L
U1 U2 1 4 2
M
1000W
100W
1400VA 1x 58W 7”F
+
c
R
1000W
+
1000W 2300W
+
3680W
MicroRex T31
92 54 29
MicroRex T31
92 54 37
MicroRex T31
A2 54 40
MicroRex QT31
92 64 28
MicroRex QW31
92 61 16
MicroRex QT31
A2 64 44
M
~
230 V~ 50 Hz 24 V~ 50 Hz 230 V~ 50-60 Hz 9-48 V AC/DC
R 100 h / +25 °C
P0,85 W 0,6 W
50 Hz ± 2 s/d +25 °C
16 A/250 V~” cos = 1Ï
1,5...4 mm2 1,5...2,5 mm2
+
-
- 10 °C ⊠+55 °C
+
- - 10 °C ⊠+60 °C
IP 30
8 mm
MicroRex
Die Schaltuhr vor ChlorgasatmosphĂ€re schĂŒtzen. Chlorgas beeinïŹusst die Funktion und Lebensdauer der Schaltuhr.
Wirkungsweise Typ 1.B. R/S. T. , IEC/EN 60730-1, IEC/EN 60730-2-7
Betrieb in ĂŒblicher Umgebung, Montage: Verteilereinbau, Verschmutzungsgrad: 2,
Schaltausgang potentialfrei
Bemessungsstossspannung: 4 kV
The time switch must be protected against chloric gas atmosphere.
Chloric gas does have an impact on life and functioning of the timeswitch.
Operating principle: Typ 1.B. R/S. T. , IEC/EN 60730-1, IEC/EN 60730-2-7,
Operation in a normal environment, Montage: in distribution panel, Degree of contamination: 2,
Switch output, potential-free
Rated impulse voltage: 4 kV
FR Lâinter horaire doit ĂȘtre protĂ©gĂ©e dâatmosphĂšre chlore gazeux.
Chlore gazeux inïŹuence la durĂ©e de vie et le fonctionnement de lâinter horaire.
Mode de fonctionnement: Typ 1.B. R/S. T. , IEC/EN 60730-1, IEC/EN 60730-2-7
Fonctionnement en environnement courant, Montage: Montage dans coffret de distribution
DegrĂ© dâencrassement: 2, Sortie logique Ă contact sec
Tension de choc nominale: 4 kV
U1 U2 1 4 2
M
4
2
24
20
22
18
16
14
10
6
8
12
800 ON ± 5 min.
600 OFF ± 5 min
800 ON ± 30 min
600 OFF ± 30 min
U1 U2 1 4 2
M
Th
12
18
6
Fr 12
18
6
Sa
12
18
6
Su 12
18
6
Mo
12
18
6
Tu
12
18
6
We
12
18
6
MicroRex T31
MicroRex QT31
18 17
16
15
14
13 12 11
10 9
8 7 6
min. 2 x 15 min
MicroRex QW31
18
12
6
7
18
12
6
6
18
12
6
5
min 2x 2 h
10
10
1
Automatik
421 4 2
ON
OFF
Sicherheitshinweise
Dieses Produkt darf nur durch eine Elektrofachkraft installiert werden, anderenfalls besteht Brandgefahr oder Gefahr eines elektrischen
Schlages. Vor der Installation die Bedienungsanleitung lesen, den produktspeziïŹschen Montageort beachten und nur Originalzubehör
benutzen. Alle Produkte dĂŒrfen ausschlieĂlich von speziell geschulten Mitarbeitern geöffnet und repariert werden. Durch unbefugte Ăffnung
oder Reparatur erlöschen alle Haftungs-, Ersatz- und GewĂ€hrleistungsansprĂŒche.
GerÀteentsorgung: Vor Entnahme des Akkus das GerÀt spannungsfrei schalten.
FR Consignes de sécurité
Ce produit doit de prĂ©fĂ©rence ĂȘtre installĂ© par un Ă©lectricien professionnel, faute de quoi vous vous exposez Ă un risque dâincendie ou
dâĂ©lectrocution. Avant dâeffectuer lâinstallation, lire la notice dâutilisation, tenir compte du lieu de montage spĂ©ciïŹque au produit et utiliser
exclusivement les accessoires dâorigine. Tous les produits doivent exclusivement ĂȘtre ouverts et rĂ©parĂ©s par des employĂ©s spĂ©cialement
formĂ©s Ă cet effet. Toute ouverture ou rĂ©paration non autorisĂ©e annule lâintĂ©gralitĂ© des responsabilitĂ©s, droits Ă remplacement et garanties.
Mise au rebut de lâappareil : Mettre lâappareil hors tension avant de retirer lâaccu.
Safety notes
This product should preferably be installed by a qualiïŹed electrician. Non-compliance may result in a ïŹre hazard or electric shocks. Before
installation, read the operating instructions and observe the product-speciïŹc requirements for the installation location. Use only original
spare parts for repair and maintenance. All products may be opened and repaired only by specially trained personnel. Unauthorised ope-
ning and repair by other persons will invalidate all claims for liability, replacement or warranty services.
Disposal: Switch off the device before removing the battery.
