GENERAL CHARACTERISTICS
With a compact footprint, the MXL AC-44 is an ideal solu-
tion for any application that requires high-quality sound
capture, including web conferencing, telemedicine, huddle
spaces, classrooms and more.
Offering crystal clear speech intelligibility, the AC-44
removes the barriers that unclear audio creates.
PLUG AND PLAY
The AC-44 Tap features an LED indicator that illuminates
blue red for active or when muted, making microphone
control a clear and transparent process for all.
Powered by a simple USB-C connection, the AC-44 Tap
offers plug and play functionality - no drivers or install-
ers are needed. Connect the mic and set it as your audio
input device.
FEATURES
• Compact Design
• Easily integrates into Telemedicine and OEM applications
or industrial workstations that require clear audio
communication.
• USB-C connection with analog 3.5mm auxiliary output
• Wide sound coverage
(180° pick up pattern I 25FT / 7.62M Range)
Miniature USB Microphone With Mute Button
Thank you for purchasing the MXL® AC-44 Tap Miniature USB Microphone. MXL Unied
Communication Microphones are the result of world-class engineering and manufacturing.
They are designed to provide you with outstanding performance and exceptional value.
For best results, please take a few moments to review this literature.
mxlmics.com
User Guide
Unied Communications
TECHNICAL SPECIFICATIONS
Type: ...................................................................USB Microphone
Capsule: ..............................3 Capsule Boundary Design
Frequency Response: 30 Hz – 20 kHz .................................
Polar Pattern: ..........................................180 º Wide Cardioid
Signal to Noise Ratio: 91 dB .........................................................
THD: -85dB ...............................................................................................
Sample Rate: ..........................................................................48kHz
Bit Depth: ......................................................................................24Bit
USB Output: USB Type C ................................................................
Analog Output: 3.5mm Line Level Direct Feed ..............
Size and Weight: 3” x 2.5” x 1” / .5 lbs........................................
Metal Finish: .........................................................................Black
Contents: .............AC-44Tap, 6’ USB C to USB Type A
WARRANTY
MXL microphones are guaranteed against defects in mate-
rial and quality for one year from date of purchase. Should
you encounter any issues with this unit, please promptly
contact the company you purchased it from for assistance.
The original dated sales receipt will be necessary for any
warranty claim. Do not send any unit directly to us without
prior authorization from our service department. Warranty
coverage is limited to repair or replacement (at our option)
of the microphone, and does not cover incidental damages
due to use, nor damage caused by accidental misuse of this
product.
