A Division of Marshall Electronics
310-333-0606
800-800-6608
Fax: 310-333-0688
www.mxlmics.com
sales@mxlmics.com
Microphone
Ensemble
Warranty
MXL microphones are guaranteed against defects in materials and workmanship
for one year from the date of purchase. If you encounter any problem with this unit,
promptly contact the company from which you purchased it for assistance. The
original dated sales receipt will be necessary for any warranty claim. Do not send
any unit directly to us without prior authorization from our service department.
Warranty coverage is limited to repair or replacement (at our option) of the
microphone, and does not cover incidental damages due to use of this unit, nor
damage caused by accidental misuse of this product.
General Characteristics
These microphones have gold-sputtered diaphragms and a xed cardioid pickup
pattern. Condenser microphones are very sensitive, readily revealing very subtle
sonic details. They also tend to pick up sounds outside the pattern more than some
designs, which can lead to powerful feedback if you are not careful. We strongly advise
experimentation with placement and isolation requirements with the gain initially set
low to avoid equipment (and ear) damage. It is strongly advised to use a mesh pop-
lter to avoid moisture from damaging the capsule.
Contents
Unpack your MXL microphone package carefully and verify that all of the following
items are included:
• 15” Mogami Cable Windscreen
Power Requirements
IMPORTANT - These units require phantom power at 48 volts, +/- 4 volts. Each unit has
been thoroughly checked before shipping, so if you do not hear sound, check that the
phantom power on your mixer or separate power supply is switched on!
Microphone Cables
Your microphone cable can have a profound effect on the sound of any
microphone. Even the nest microphones will sound poor if the interconnect
cable allows noise to enter, or causes distortion and loss of information. We highly
recommend the Mogami® Cable supplied with the microphone.
Care
Dust and foreign material can degrade the performance of a microphone over time,
so always store the unit in its box. For vocals closer than 3”, use a pop lter or a foam
windscreen to avoid getting moisture on the diaphragm as this can substantially
degrade the microphone’s performance. Store the microphone in its original
packaging in a cool, dry place along with the included packet of silica gel.
Thank you for choosing the MXL 550/551 Recording Ensemble. For best results,
please take a few moments to read this manual and familiarize yourself with
proper operation and care of your microphone.
Microphone Ensemble
• MXL 550 mic
• MXL 551R mic
• Hard Mount Mic Stand Adapter
• Hard Mount Instrument Mic Adapter
• Rugged Carrying Case
Type: ...........................................Pressure gradient condenser microphone
Frequency Range: .............................................................................. 30 Hz – 20 kHz
Polar Pattern: ......................................................................................................Cardioid
Sensitivity: ............................................................................................................15mV/Pa
Impedance: .................................................................................................................200Ω
S/N Ratio: 80dB (Ref. 1Pa A-weighted) ...................................................................
Equivalent Noise Level: ................................ 20dB (A weighted IEC 268-4)
Max SPL for 0.5% THD: 130dB ..........................................................................................
Power Requirements: ...................................48V Phantom Power (+/- 4V)
Current Consumption: ................................................................................... <3.0mA
Size: ............................................................................................................47mm x 170mm
Weight: ..........................................................................................................................0.8 lbs
Metal Finish: ...........................................................................Red with chrome grill
Frequency ChartPolar Pattern
Type: ...........................................Pressure gradient condenser microphone
Frequency Range: .............................................................................. 30 Hz – 20 kHz
Polar Pattern: ......................................................................................................Cardioid
Sensitivity: ............................................................................................................15mV/Pa
Impedance: ....................................................................................................................110Ω
S/N Ratio: ....................................................................78dB (Ref. 1Pa A-weighted)
Equivalent Noise Level: ................................ 20dB (A weighted IEC 268-4)
Max SPL for 0.5% THD: ...........................................................................................137dB
Power Requirements: ...................................48V Phantom Power (+/- 4V)
Current Consumption: ................................................................................... <3.0mA
Size: ........................................................................................................... 22mm x 134mm
Weight: ..........................................................................................................................0.2 lbs
Metal Finish: ...........................................................................Red with chrome grill
Frequency ChartPolar Pattern
