Imarflex IG-730 Manual
Read below 📖 the manual in Italian for Imarflex IG-730 (4 pages) in the Oven category. This guide has been helpful for 3 people and has been rated 4.5 stars on average by 2 users
Page 1/4
SPECIFICATION
IMPORTANT SAFEGUARDS
1. Read all instruction carefully before use.
2. Before using the unit, always check the hose and regulator to avoid leakage.
3. Put the unit in stable surface and keep it away from the edge of the counter to avoid
accident.
4. Keep curtains, furniture, appliances, ammable materials, etc. away from the unit.
5. Children should be supervised to ensure that they do not play with the appliance.
6. This appliance is not intended for use by person (including children) with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge, unless they have been
given supervision or instruction concerning use of the appliances by a responsible for their
safety.
7. Do not use gas other than LPG.
8. This appliance is designed for cooking and not intended for any other purpose.
9. If you notice that the ame is not normal you smell gas leakage, turn OFF the unit and or
bring it to the nearest Authorized Service Center.
10. Do not use this unit for outdoor use.
11. Do not use this unit other than its intended use.
12. For household use only.
13. Save this instruction manual for future reference.
DESCRIPTION OF PARTS
Model : - IG 530
IG- 570
Gas : Liqueed Petroleum Gas (LPG)
Gas Pressure : 2000pa
2000pa
Gas Consumption: 3.55 kW
7.1 kW
Dimension : (L)x385(D)x115(H) 300 mm
700(L)x370(D)x115(H)mm
INSTALLATION
1. Check all parts of the gas stove, including the following:
• Trivet (1pc for Single Burner / 2pcs for Double Burner)
• Control knob (1pc for Single Burner / 2pcs for Double Burner)
• 4pcs. footing
2. Connect 3/8” hose at the gas stove inlet pipe and the other in the regulator/valve. Fasten end
the hose in both sides by tightening the hose clamp rmly. (See illustration 1)
3. Place the gas stove away from the wall or ceiling.
(See ustration 2) ill
HOW TO USE
1. Make sure that the control knob is in OFF position. (See g. 1.)
2. Open the regulator/valve of the gas tank. (Pull or twist)
3. Push down the control knob and turn it counter clockwise until click sound is heard. The
ame ignites automatically with the spark system.
4. If ignition fails due to faulty gas ow, turn the control knob back to OFF position and repeat
instruction #3.
5. If you want to use high ame, turn the control knob as shown in g. 2.
6. If you want to use the low ame of the inside ring, turn the control knob as shown in g. 3.
7. If you want to use both rings with low ame, turn the control knob as shown in g. 4.
8. If the ames become yellowish, adjust the gas and air mixture control to produce luminous
ames. (See Fig. 5)
9. After use always turn OFF the regulator/valve of the gas tank.
FIRE PREVENTION TIPS IN USING GAS STOVE
1. Install gas tank in an open air (clear air ).
2. After every use, close the regulator/valve of the gas tank in order to minimize the remaining
gas pressure in the hose.
Product Specifications
| Brand: | Imarflex |
| Category: | Oven |
| Model: | IG-730 |
