Imarflex IDX-1500 Manual
Read below đ the manual in Italian for Imarflex IDX-1500 (4 pages) in the Oven category. This guide has been helpful for 6 people and has been rated 4.5 stars on average by 2 users
Page 1/4
SPECIFICATION
MODEL NO. : IDX-1500
RATED VOLTAGE : 230Va.c. 60Hz ~
POWER CONSUMPTION : 1800 watts
IMPORTANT SAFEGUARDS
When using electrical appliances, basic safety precautions should
always be followed, including the following:
1. Read all instructions carefully.
2. Do not use the unit on any metal table.
3. Do not place the Induction Cooker next to devices, which react
sensitively to magnet (e.g. radios, TV, cassette recorders, etc.).
4. Keep curtains, furniture, îammable materials, etc. away from the unit
and from the convenience outlet where the unit is plugged.
5. Before using the unit, check if the voltage indicated corresponds with
the convenience outlet (230Va.c.)
6. Do not use any appliance with a damaged cord or plug. If the cord is
damaged it should be replaced with the same type and size or bring
the unit to the nearest authorized
service center.
7. Do not use two-way socket with other
appliance.
8. Do not touch the unit and the power
plug with wet hands.
9. Do not block the ventilation slots of the
unit. Keep a minimum distance of cm 10
to cm from the wall or from other 20
items.
10. The Induction Cooker's surface is made of temper glass, in case ed
of damage, unplug immediately.
11. Do not insert any objects like wires or tools into the ventilation slots,
this may cause electric shocks.
12. The Induction Cooker does not heat up during cooking, but the heat
from the cookware, transmit in the Induction Cooker. Do not touch
the hot surface of the glass.
13. Scientiîc tests have proven that Induction Cookers are safe to use.
However, persons with a pacemaker should keep a minimum
distance of 60cm from the unit while using.
14. Do not place any metal kitchen utensils, pan lids, knives or other
metal objects on the cooker. These may heat up when the unit is
turned on.
15. Do not place any magnetic objects on the glass surface while the
unit is in use.
16. To protect against electric shock, do not immerse the unit in water.
-1-
KW/hr CONSUMPTION KEY
1. While the unit is in use, press kw/hr key to check the POWER
usage. The LED display will show the total POWER usage.
2. Press this button twice. The LED display will show the input
VOLTAGE.
TIMER KEY
1. Press TIMER key.
2. Press DOWN arrow to change the HOUR setting and press UP
arrow to change the MINUTE setting.
3. To re-set the TIMER back to zero, simply turn OFF and turn ON
again.
TROUBLE SHOOTING
PROBLEM
TROUBLE SHOOTING
No power on Light Indicator
and LED Display
1. Unplug and plug it again.
2. Check for damage
The unit doesnât heat-up
and the Light Indicator is
blinking.
1. Wrong Cookware.
2. Cookware is not in the center of
the Induction Plate.
The unit doesnât heat-up
and the Light Indicator is
blinking (E1 appeared on
the LED Display)
1. The voltage might be too low or
too high (Ideal voltage should be
200-240 volts).
2. Unplug and plug it again.
The unit doesnât heat-up
and the Light Indicator is
blinking (E4 appeared on
the LED Display)
1. Maybe the pan temperature is too
high. Choose a FUNCTION
wherein temperature is
adjustable.
CLEANING AND MAINTENANCE
1. Always unplug the unit from the convenience outlet before
cleaning.
2. Wipe the Body and the Induction Plate with damp cloth,
regularly.
3. Do not use chemical base solution.
-6-
SUITABLE COOKWARES:
Magnetized stainless steel and cast iron
UNSUITABLE COOKWARES:
Non-magnetized stainless steel, aluminium, plastic, glass, and porcelain
CONTROL PANEL
OPERATING INSTRUCTION S:
1. Put the induction-ready cookware on the center of the Induction
Plate.
2. Plug in (ON/OFF light indicator will blink, indicating that unit is in
STAND-BY mode).
3. Press ON/OFF control key, to turn the unit ON.
4. The default FUNCTION is set on HOT P OT
CAUTION: Do not leave an empty cookware with the Induction Cooker ON.
Pre-set Function Table:
Press the FUNCTION key to switch from one function to another.
PRE-SET
FUNCTIONS
LIGHT
INDICATOR
PROCEDURE
HOT POT
NOTE:
Pre-set
WATTAGE is
â1300â watts.
HEAT
(watts)
1. Press the ON/OFF key, HOT
POT light indicator will turn
ON.
2. To change the WATTAGE:
Press the DOWN/UP arrow
keys to change power setting
from 300W to 1800W.
3. To set the TIMER: Press
TIMER key, press DOWN
arrow to change the HOUR
setting and press UP arrow to
change the MINUTE setting.
-3-
PRE-SET
FUNCTIONS
LIGHT
INDICATOR
PROCEDURE
COOK
NOTE:
Pre-set
TEMPERATURE
is 200°C.
TEMP
(°C)
1. Press FUNCTION key once,
COOK light indicator will turn
ON.
2. To change the TEMPERATURE
Setting: Press the DOWN/UP
keys to change the setting.
(Temperature stages: 60, 90,
140, 200, 220, 240, and 270°C)
To set the TIMER: Press TIMER
key, press DOWN arrow to change
the HOUR setting and press UP
arrow to change the MINUTE
setting.
DEEP FRY
NOTE:
Pre-set time is
â2:00â HOURS
While cooking,
simply press the
timer key to view
the remaining
Time on the LED
display.
Once the set
Time is up, a
beep sound will
be heard and the
cooking process
will automatically
stop.
TIME
(hh:mm)
1. Press the FUNCTION key twice,
DEEP FRY light indicator will
turn ON.
2. set the TIMER: Press TIMER To
key, press DOWN arrow to
change the HOUR setting and
press UP arrow to change the
MINUTE setting.
Reminder:
Let the induction cooker pre-heat
the oil îrst before putting any food
for frying.
-4-
Product Specifications
| Brand: | Imarflex |
| Category: | Oven |
| Model: | IDX-1500 |
