Imarflex IDX-1600 Manual
Read below 📖 the manual in Italian for Imarflex IDX-1600 (3 pages) in the Oven category. This guide has been helpful for 3 people and has been rated 4.5 stars on average by 2 users
Page 1/3
CLEANING AND MAINTENANCE:
1.) Always unplug the unit from the convenience outlet before
cleaning. Let it cool.
2.) Wipe the Body and the Induction Plate with damp cloth,
regularly.
3.) Do not use chemical solution.
-7-
SPECIFICATION:
MODEL NO. : IDX-1600
RATED VOLTAGE : 230Va.c. ~ 60Hz
POWER CONSUMPTION : 00 Watts 20
IMPORTANT SAFEGUARDS
When using electrical appliances, basic safety precautions should
always be followed, including the following:
1. Read all instructions carefully.
2. Do not use the Induction Cooker on any metal table.
3. Do not use the Induction Cooker next to devices, which react
sensitively to magnet (e.g. radios, TV, cassette recorders, etc.).
4. Keep curtains, furniture, ammable materials, etc. away from the
unit and from the convenience outlet where the Induction Cooker
is plugged.
5. Before using the Induction Cooker, check if the voltage indicated
corresponds with the convenience outlet (230Va.c.)
6. Do not use any appliance with a damaged cord or plug. If the
cord is damaged it should be replaced with the same type and
size or bring the unit to the nearest Authorized Service Center.
7. Do not use two-way socket with other appliance.
8. Do not touch the Induction Cooker and the power plug with wet
hands.
9. Do not block the ventilation slots of the Induction Cooker. Keep a
minimum distance of 10cm to 20cm from the wall or from other
items.
10. The Induction Cooker’s surface is made of ceramic, in case of
damaged, unplug immediately.
11. Do not insert objects like wires or tools into the ventilation slots,
this may cause electric shocks.
12. The Induction Cooker does not heat up during cooking, but the
heat from the cookware, transmit in the Induction Cooker. Do not
touch the hot surface of the glass.
13. Scientic tests have proven that Induction Cookers are safe to
use. However, persons with a pacemaker should keep a
minimum distance of 60cm from the Induction Cooker while
using.
14. Do not place any metal kitchen utensils, pan lids, knives or other
metal objects on the cooker. These may heat up when the
Induction Cooker is turned on.
15. Do not place any magnetic objects on the glass surface while the
Induction Cooker is in use.
16. To protect against electric shock, do not immerse the Induction
Cooker in water.
-1-
NOTE: The unit is equipped with an overload protection. If the
pot or pan gets too hot, a beep sound will be heard and the
unit will automatically turns OFF Unplug the unit from the .
convenience outlet and let it cool.
TROUBLE SHOOTING
PROBLEM
1. There is noise while using.
2. There is sound and a “beep”
the “ON/OFF” light flash, no
heating.
3. Stop heating while using.
4. No response from the key.
POSSIBLE CAUSES
1. a There is noise when the
exhaust fan is working,
please check if it is coming
from the exhaust.
1. Please check if the pot is
suitable for Induction Cooker.
2. If the pot is not placed at the
center of the ceramic plate.
1. Please check if the
temperature around is too
high.
2. If the air-in or exhaust hole is
blocked.
3. If the t time is nished. se
1. Please check if it is properly
plug . ged
-6-
CONTROL PANEL
ELECTRICITY VOLTAGE- to check the voltage of the unit
1. Press this button to check the voltage while in use.
PRESET BUTTON- to set a delay time cooking
1. On stand by mode, press this button, default time is 2 hours.
2. Press - keys to “/+” adjust the time from “1 minute 24 hours”.-
3. Press ON/OFF button. Preset function is HOTPOT. Press the
Function Button to select the desired cooking preset function.
4. After the preset time, the unit will automatically turn ON and
work on the set cooking preset function
- -“ “BUTTON to decrease setting
1. While cooking, press this button to decrease the Time,
Temperature and Wattage.
ON/OFF BUTTON- to turn the unit ON and OFF.
“+” BUTTON- to increase setting
1. While cooking, press this button to increase the Time,
Temperature and Wattage.
“TIMER” BUTTON- to set cooking time.
1. Press ON/OFF button, HOTPOT is the preset function, press the
Function button to select desired function.
2. - desired setting. Press the “ /+” keys to select
3. Set the desired cooking time by pressing the “TIMER” button,
adjust time by pressing “ /+” keys, press 1 it will -
increase/decrease by 1 minute, long press it will
increase/decrease by 10 minutes.
4. After the set time, the unit will automatically shut o.
FUNCTION BUTTON- to select desired cooking function.
1. Turn on the unit, HOTPOT is the preset function,
2. Press this button to select desired cooking function.
-3-
HOW TO USE
1. Put the induction-ready cookware on the center of the Induction
Plate.
2. Plug in. A “beep” sound will be heard, (ON/OFF light indicator
will blink, indicating that unit is in STAND-BY mode).
3. Place the cookware with load on the unit.
4. Press ON/OFF control key, to turn the unit ON.
5. The function is set on HOTPOT Function.
CAUTION: Do not leave an empty cookware with the Induction
Cooker ON.
PRESET FUNCTION TABLE:
PRE- SET
FUNCTION
HOTPOT
NOTE:
Preset WATTAGE
is “20 Watts” 00
Preset TIME is
“2:00 Hours”
PORRIDGE
NOTE:
Default
WATTAGE is
“1000 Watts”
Default TIME is
“2:00 Hours”
FRYING
NOTE:
Default
TEMPERATURE
is “240ºC”
Default TIME is
“2:00 Hours”
LIGHT
INDICATOR
HEAT
(Watts)
HEAT
(Watts)
HEAT
(ºC)
PROCEDURE
1. Press the ON/OFF key,
HOTPOT light indicator will turn
ON.
2. To change the wattage: Press
the -/+ keys to change power
setting from 100W- 00W. 20
1. Press the Function Button to
select “PORRIDGE” Function,
indicator will turn ON.
2. To change the wattage: Press
the -/+ keys to change power
setting from 100W- 00W. 20
1. Press the Function Button to
select the “ROAST” function light
indicator will turn ON and LCD
will display 240ºC.
2. Press the -/+ keys to change the
temperature from 60ºC to 270ºC.
-4-
Product Specifications
| Brand: | Imarflex |
| Category: | Oven |
| Model: | IDX-1600 |
