Imarflex IG-630T Manual
Read below 📖 the manual in Italian for Imarflex IG-630T (4 pages) in the Oven category. This guide has been helpful for 3 people and has been rated 4.5 stars on average by 2 users
Page 1/4
SPECIFICATION:
Model: IGS- T/IGS-630 656S
Gas: Liqueed Petroleum Gas (LPG)
Gas Pressure: 2800Pa
Gas Consumption: Left Burner: 3.5kW Right Burner: 4.0kW
Dimension: 680mmX400mmX7 m 0m
Net Weight: 5.09kg
IMPORTANT SAFEGUARDS
1. Read all instructions carefully.
2. Before using the unit, always check the hose to avoid leakage.
3. Put the unit on stable surface keep it away from the edge of counter to avoid accident.
4. Keep curtains, furniture, ammable materials, etc. away from the unit.
5. Children should be supervised to ensure that they do not play with the appliance.
6. This appliance is not intended for use by persons (including children) with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge, unless they have been
given supervision or instruction concerning use of the appliances by a person responsible
for their safety.
7. Do not use a gas other than which is specified on the label attached on appliances.
8. This appliance is designed for cooking and not intended for any other purpose.
9. Do not cover burner with plate.
10. If you notice the ame burning abnormally or you smell gas, turn appliances OFF and bring
the unit to the Authorized Service Center.
11. Do not use the unit for outdoor use.
12. Do not use this unit other than its intended use.
13. For household use only not intended for any business purposes.
14. Save this instruction manual for future reference.
DESCRIPTION OF PARTS
SETUP AND INSTALLATION:
1. Check all parts of gas stove including the , ff:
2pcs. Gas burner, 2pcs an rack 2pcs. Switch knob . P ,
2. Connect 3/8-inch rubber tube at the end of the gas tube and tie the belt rmly.
3. For installation, the stove should be far from the wall or ceiling.
HOW TO USE:
1. Make sure that the control knob is in OFF position. (See g. 1.)
2. Open the regulator/valve of the gas tank. (Pull or twist)
3. Push down the control knob and turn it counter clockwise until click sound is heard. The
ame ignites automatically with the spark system.
4. If ignition fails due to faulty gas ow, turn the control knob back to OFF position and repeat
instruction #3.
5. If you want to use high ame, turn the control knob as shown in g. 2.
6. If you want to use the low ame of the inside ring, turn the control knob as shown in g. 3.
7. If you want to use both rings with low ame, turn the control knob as shown in g. 4.
8. If the ames become yellowish, adjust the gas and air mixture control to produce luminous
ames. (See Fig. 5)
9. After use always turn OFF the regulator/valve of the gas tank.
Product Specifications
| Brand: | Imarflex |
| Category: | Oven |
| Model: | IG-630T |
