(English Version)
CODE FROM SERIAL NO: PART NUMBER: 111-2300 (A)
432F 280000001
433F 280000001
434F 280000001
435F 280000001
ISSUE 23.05.2008
OWNER'S HANDBOOK
Motif
CODES
432F 433F 434F 435F
(Auto Drive) (Push) (Auto Drive) (Push)
111-2300 (A) 4/6/08 11:27 am Page 1.1
Engine (435)Honda GCV 135 (Codes 432/433/434) GCV 160
Engine type GCV135EA4G7SD GCV160EA4G7SD(432/433/434) (435)
Engine/Cutterbar speed (433/434)2900 rpm (432/435) 2700rpm
Fuel type Unleaded petrol
Fuel capacity 0.9 litres , 1.1 litres (432/433/434) (435)
Oil type SAE 10w-30 engine oil
Oil sump capacity 0.55 litres
Cutting width 410mm 480mm 530mm (432) (433/434) (435)
Cutting height 25 - 55mm
Overall dimensions (432) 1,010 x 490 x 1,395mm 985 x 530 x 1,415mm (433/434)
975 x 570 x 1,500mm (435)
Dry Weight 31Kg (432) (433) 31.8Kg 34Kg (434) 36Kg (435)
1
2
3
4
5
6
7
8
9
10 11
14
12
13
Main Features
Specifications
MAIN FEATURES / SPECIFICATIONS
1.2
1. Spark Plug Lead
2. Fuel Filler Cap
3. Oil Filler Cap and Dipstick.
4. Handlebar Securing Knob
5. Rope Guide
6. Engine Start-Grip
7. Engine Stop lever
8. Handlebar
9. Ground Drive Clutch Lever
(Auto drive only)
10. Rear Deflector
11. Grassbag Assembly
12. Serial Number Decal
13. Height of Cut Adjuster
14. Throttle Control
111-2300 (A) 4/6/08 11:27 am Page 1.2
1st Year (12 months)
We certify that this service has been
carried out by an Authorised Hayter
Service Dealer
Date:
1st Year (12 months)
Owner’s Name:
Serial Number:
Date:
2nd Year (24 months)
We certify that this service has been
carried out by an Authorised Hayter
Service Dealer
Date:
Owner’s Name:
Serial Number:
Date:
Note for dealer: Please retain this voucher for your records.
Note for dealer: Please retain this voucher for your records.
2nd Year (24 months)
111-2300 (A) 4/6/08 11:27 am Page 1.3
