Page 1/36
OWNER’S HANDBOOK
(English Version)
FROM SERIAL NO: 422V001001, 423V001001, 424V001001 HANDBOOK: 422064 (Re .0.)v
Issue : March 2001
JUBILEE
CODES
422V . 423V . 424V
(Push) (Push) (Auto Drive)
Engine Briggs & Stratton Quantum XM 45
Engine type 127802-2005-E1 (422N/423N) (424N)127802-2004-E1
Engine/Cutterbar speed 2900 rpm
Fuel type Unleaded petrol
Fuel capacity 1.5 litres
Oil type SAE 30 engine oil
Oil sump capacity 0.6 litres
Cutting width 430mm (422N) 480mm (423N/424N)
Cutting height 19 - 70mm
Overall dimensions (422N/423N) 1,430 x 550 x 1,050mm 1,550 x 550 x 1,050mm (424N)
Dry Weight 27.7Kg (422N) (423N) (424N)29.9Kg 30.4Kg
1. Primer Bulb.
2. Fuel Filler Cap.
3. Oil Filler Cap and Dipstick.
4. Handlebar Securing Knob.
5. Rope Guide.
6. Engine Start-Grip.
7. Engine Stop lever.
8. Handlebar.
9. Ground Drive Clutch Lever (Auto drive only).
10. Rear Deflector.
11. Grassbag Assembly.
12. Serial Number Decal.
13. Height of Cut Adjuster.
14. Spark Plug Lead.
1D42205A
30
4
8
9
11
10
12
13
14
1
23
4
5
6
7
MAIN FEATURES / SPECIFICATIONS
1.2
Main Features
Specifications
1.18 Maintenance Schedule
1.19 - 1.25 Mower Maintenance
1.19 - Engine
1.19 - Carburettor Adjustments
1.20 - Oil Service
1.20 - Air Cleaner Service
1.21 - Spark Plug Service
1.21 - Keeping Engine Clean
1.21 - Grassbag
1.22 - Deck Housing
1.22 - Securing Nuts and Bolts
1.22 - Clutch Cable Adjustment
1.23 - Lubrication
1.23 - Cutterblade Removal
1.24 - Cutterblade Assembly -
Push Models
1.24 - Cutterblade Assembly -
Autodrive Models
1.24-1.25 - Cutterblade Sharpening
1.25 - Storage
1.26 - 1.27 Trouble Shooting
1.28 Declaration of Conformity
1.29 - 1.31 Parts List
1.32-1.34 Parts list Diagrams
1.35 Customer Information/Notes
1.2 Main Features/Specifications
1.3 Contents
1.4 Introduction
1.5 Warranty
1.6 - 1.9 Safety Precautions
1.9 Safety Symbols
1.9 Decal Symbols
1.10 Assembling the Mower
1.10 - Delivery Checklist
1.10 - Handlebar
1.10 - Grassbag Attachment
1.11 Before Starting the Mower
1.11 - Prevent Engine Damage
1.11 - Oil Type
1.11 - Check Oil Level
1.11 - Fuel Type
1.12 - 1.15 Operating The Mower
1.12 - Controls
1.12 - Starting Step 1
1.12 - Step 2
1.12 - Forward Travel
1.13 - Turning
1.13 - Stopping
1.13 - Slopes
1.13 - Height of Cut
1.14 - Before Mowing
1.14 Grassbag -
1.14 - Without Grass Collection
1.14 - Heavy Growth
1.15 - Non-Grassed Areas
1.16 - 1.17 Lawn Care Calendar - Guide Only
CONTENTS
1.3
