Page 1/36
Operating Instructions
METRA HIT27EX
Milliohmmeter for deployment
in potentially explosive atmospheres 3-349-336-49
13/4.24
2 Gossen Metrawatt GmbH
1 Display (LCD)
2 ON|OFF key for ON / OFF
(ON short: instrument ON ON short: background illumination ON
OFF short: background illumination OFF OFF long: instrument OFF)
Operating mode menu: open submenus / acknowledge entries
3 DATA|CLEAR key for the functions save/delete measured value
Operating mode menu: Selection of individual menu items
against direction of flow,
increase values
4 MAN|AUTO key for manual measuring range selection
Operating mode menu: Selection of individual menu items
in direction of flow
decrease values
5MENU/ESC
Operating mode menu: Exit menu level and
return to a higher level,
exit parameters configuration
without saving data
6 LED blinks: valid measured value OK
7 LED blinks: incorrect connectionERROR
8 Connector jacks *
1
2
6
4
5
8
Measurement only on
voltage-free objects!
chapter 5
chapter 3
chapter 4
chapter 7.2
chapter 7.3
chapter 7
7chapter 7.3
3chapter 6
Gossen Metrawatt GmbH 3
GB
Symbols used in the Digital Display
1 Main display with decimal point
2 Auxiliary displays
3 : Milliohmmeter in continuous operation,
ON blinks at transmission frequency in transmission mode
4 REM: Memory mode operation, disappears after communication
via the interface is ended by means of key or switch
operation
5 ZERO: Zero balancing
6 MAN: Manual measuring range selection
7 Unit of measure (if blinking, refer to chapter 11 on page 33)
8 Low battery voltage, replace batteries:
* I- Measurement input
U- Sense – for 4-wire measurement
U+ Sense + for 4-wire measurement
I+ m ; measurement input
1
2
8
64 53
7
