4017C Shotgun Microphone
A combination of the MMC4017 microphone capsule and the MMP-C
preamplifier, the 4017C Shotgun Microphone is part of the Pencil
Microphone Series.
Performance
The supplied calibration chart shows the specially tailored
individual frequency response of the MMC4017 capsule, measured
with a linear MMP-C preamp.
Typical on- and o-axis frequency response of MMC4017
Typical directional characteristics of an MMC4017
dpamicrophones.com/4017
DPI-4017C-QG
Service & repair
If you are not satisfied with the characteristics exhibited by this product, please contact your nearest DPA
Microphones representative for support.
Warranty
4017C is covered by a five-year limited warranty.
CE marking
This product conforms with all relevant directives approved by the European Commission.
20 Hz 50 100 200
500
1 kHz 2 5 10 20 40
dB
10
-10
-20
-30
0
0°
30°
60°
90°
140
°
16 kHz
8 kHz
4 kHz
2 kHz
1 kHz
500 Hz
250 Hz
0º
5dB
Specifications
Directional pattern
Supercardioid, lobe-shaped
Principle of operation
Pressure gradient, with interference tube
Capsule type
Pre-polarized condenser
Frequency response
20 Hz to 20 kHz
Eective frequency range, ± 2 dB, at 60 cm (23.6 in)
40 Hz to 18 kHz with typ. 3 dB soft boost at 15 kHz
Sensitivity, nominal, ± 2 dB at 1 kHz
19 mV/Pa, -34.4 dB re 1 V/Pa
Equivalent noise level, A-weighted
Typ. 13 dB(A) re. 20 Pa (max. 15 dB(A))µ
Rated output impedance
< 100 Ω
Output balance principle
Impedance balancing with Active Drive
Common Mode Rejection Ratio (CMRR)
> 50 dB
Power supply (for full performance)
P48 (Phantom power)
Current consumption
2.8 mA
Polarity
+V at Pin 2 for positive sound pressure
Connector
XLR-3M. Pin 1: Shield, Pin 2: signal + phase, Pin 3: signal – phase
Weight
40 g (2.5 oz)
Temperature range
-40 °C to 45 °C (-40 °F to 113 °F)
Relative humidity
Up to 90%
