Page 1/6
VMPUî€ -100L
Easyî€ Setupî€ Guide
G
Itemsî€ Included
Monitorî€ Bracket
x(4)
Screenî€ mount
x(1)
Gusset
x(4)
C
M5î€ xî€ 40î€ Bolt
x(4)
M5î€ xî€ 10î€ Bolt
x(8)
www.avteq.net
M4î€ x12î€ Boldî€ x(8) M5î€ x12î€ Boldî€ x(8) M6î€ x12î€ Boldî€ x(8) M8î€ x16î€ Boldî€ x(8)
M4î€ x30î€ Boldî€ x(8) M5î€ x30î€ Boldî€ x(8) M6î€ x35î€ Boldî€ x(8) M8î€ x40î€ Boldî€ x(8)
M6î€ Lockî€ Washer
x(8)
M8î€ Lockî€ Washer
x(8)
M6î€ Lockî€ Washer
x(8)
M6î€ Lockî€ Washer
x(8)
M5î€ Lockî€ Washer
x(8)
M4î€ Lockî€ Washer
x(8)
P
M6î€ Lockî€ Washer
x(8)
M4/M5î€ Spacer
x(8)
M6î€ Lockî€ Washer
x(8)
M6/M8î€ Spacer
x(8)
M4/M5î€ Washer
x(16)
M6/M8î€ Washer
x(8)
Concrete Anchorî€ 3/8”
x(8)
Lagî€ Boltî€ Washer
x(8)
Lagî€ Boltî€ 3/8” xî€ 2”
x(8)
Assemblyî€ instructionsî€ forî€ theî€ VMPU-100L.
Note: Theî€ suppliedî€ wallî€ mountingî€ hardwareî€ isî€ notî€ forî€ steelî€ studî€ wallsî€ orî€ oldî€ cinderî€ blockî€ walls,î€ Ifî€ youî€ areî€ uncertain
aboutî€ theî€ natureî€ ofî€ yourî€ wall,î€ consultî€ anî€ installationî€ contractor.
Required Tools:î€ 3/16î€ drillî€ bit,î€ 1/2"î€ Masonryî€ Bitî€ forî€ brickî€ concreteî€ orî€ concreteî€ blockî€ installations,î€ wrenchî€ orî€ socketî€ set,
Phillipsî€ screwî€ driver
B
A
V
W
X
U
S
R
Q
T
LMN
O
K
F
Hi
J
E
D
G
D
D
www.avteq.net
C
E
ASecureî€ theî€ extension
toî€ theî€ monitorî€ bracket.
