PS Series Mounting System Instructions
PS-50-32 / PS-50-24
Slide Central Support onto Screen
Mount from side.
PS-ABV
Acrylic
L-Support
Bracket
Countersunk
Bolt
Acorn Nut
Buttonhead
Bolt 1/4 x 3/4โ
Separate all pieces.
Step 1
Allen
Wrench
Central
Support
x4
x1
x4
For assistance call 1.800.285.8315
PS Series Mounting System Instructions
PS-ABV (continued)
Step 4
Bolt Acrylic onto L-Support Bracket
using the four Countersunk Bolts
and Acorn Nuts.
Step 2 Step 3
Slide PS-ABV into Central Support
and lock in place at desired height
using tabs.
Secure PS-ABV to Central Support
using the Buttonhead Bolt
For assistance call 1.800.285.8315
PS Series Mounting System Instructions
PS-CTR
Step 1
Acrylic Center
Extension
Countersunk
Bolt
Acorn
Nut
Buttonhead
Bolt 1/4 x 3/4
Buttonhead
Bolt 1/4 x 1
Seperate pieces.
Step 2
Bolt Acrylic to Center Extension
using the four Countsunk Bolts and
for Acorn Nuts
Central Arm
x4
x1 x4 x1
