TilTing FlaT Panel TV MounT For 40-65” TeleVisions

User’s Guide for Model No. TM35 v1381-01

STEP 1

Horizontal Base Plate

• AssembledHorizontalBasePlate.

NotemountingpointswhichwillbeusedforStep2.

Front Towards TV

Rear Towards Wall

Wall Mounting Points

• Concrete/Brickwallshown.Drillsixholesforsolidwallapplication.

• Usea3/8”or10mmdrillbit.

• Cutawayofdrywallwithstudsshownbehind.Drillfourholesforstud

application.UseastudndertolocateandONLY DRILL INTO STUDS!!

• Usea5/32”drillbit.

STEP 2

Pre-drill Holes for Base Plate

• DrillholesfortheBasePlatetoattachtothewall,usingexact

measurementsbasedonwhereyouwanttomounttheHorizontalBase

Plate.Onlydrillintoasolidwall,orstuds(behinddrywall).DO NOT

DRILL AND HANG THE BASE PLATE ON DRYWALL OR SHEETROCK.

ItisnotstrongenoughtosupportaTVandwillcausedamage.

WARNINGS

• ThewallmountedpartsoftheTVmountmustbermlyattachedtoa

concrete/brick/solidwoodwall,orwallstudsbehinddrywall.

• Tightenscrewssothatthewallplateisrmlyattached,butdonot

overtighten.Overtighteningcandamagethescrewsandincreasethe

chancesoffailure.

• Donotremoveorloosenanyscrewsuntiltheyarenolongerengaged

withthemount.Doingsomaycausethescreentofall.

• Itishighlyrecommendedtohavethismountprofessionallyinstalled.

• Supports VESA up to 600 x 400mm.

• This mount is designed to hold a maximum of 132 lbs (60 kg).

TOOLS

Thefollowingtoolsarerecommendedforthisinstallation:

• Drill

• 5/32”drillbitfordrywall

• 3/8”or10mmdrillbitforconcrete

• Studnder

• Phillipsscrewdriver

PARTS

A x4

M8x15

x4B M6x15

x4C M5x15

x4D Ø5

x4E Ø6

x4F Ø8

Ø15xØ8x4.5 x4G

x1H

x2M

x2O M6x38

L x6

Ø10x50

x6K M6x50

x2I M6x10

x1J Mag Level

x2N M6x15

Horizontal Base Plate x1

x2I M6x10

x1H

Horizontal Base Plate x1

• Thehorizontalbaseplateisalreadypartiallyassembledfromthefactory.

Screwtheremainingverticalbarintothecentersectionofthebaseplate

asshown.Noteorientationofparts.

Note: Parts A-G are used to attach

your TV to the brackets in Step 4,

but you will not need all of them.

Find and use the set that best ts

your specic TV.

TilTing FlaT Panel TV MounT For 40-65” TeleVisions

User’s Guide for Model No. TM35 v1381-01

STEP 4

Attach Brackets to Television

STEP 5

Attach Television to Wall

STEP 3

Attach Base Plate to Wall

• Tightenthetwosafetyscrewsonthebottomofthebracketuntilthey

are againstbaseplate.ThesescrewssecuretheTVtothebaseplateFIRM

andensureitwillnotmoveorshiftafterinstallation.

• AttachtheHorizontalBasePlatetothewallusingtheholesdrilledinStep

2.UsetheincludedleveltoensuretheHorizontalBasePlateiscorrectly

alignedandsquare.

• Ifattachingtoasolidwall,useallsixofPartsKandLtomount.If

attachingtostuds,usefour.

• InsertwallanchorsintotheholesdrilledinStep2,thenscrewthebase

platermlytothewallwiththesuppliedscrews.

x6K M6x50

x2M

x1J Mag Level

x2O M6x38

x2N M6x15

PARTS A  G

L x6

Ø10x50

• Attachthetwobracketstotherearofyourtelevision,makingsurethe

clawofthebracketisintheupperposition.

• Usetheincludedscrewsandwashers(PartsA-F)tosecurethebracketto

yourTV.FindthesetthattsyourTVanddiscardtherest.

• Therubberwashers(PartG)canbeusedasaspacerbetween the TV

body and the mounting brackets, ifthemountingholesontheTVare

tooshallowfortheincludedscrews.

• AttachtheTV/bracketstotheHorizontalBasePlateonthewall,making

suretocatchthetopclawofthebracketontherimoftheupperbase

plate.Usethetwolongsafetyscrewstotightenthebracketstothebase.

• ItishighlyrecommendedtouseatleasttwopeopletohangtheTV.

Screw & Washer

OPTIONAL

SPACER O

AF
