Page 1/4

FULL MOTION FLAT PANEL TV MOUNT FOR 28-65” TELEVISIONS

User’s Guide for Model TM65 v1568-01

! x6

STEP 1

Level and Pre-drill Holes for Mount

• Usetheincludedleveltoensurethemountiscorrectlyalignedand

square,thenmarkholesfordrilling.

• Drill6holesforthemounttoattachtothewall.Onlydrillintoasolidwall,

orthewoodenstudsbehinddrywallorsheetrock.

• usea5/32”drillbit.For drywall and studs,

• For solid/concrete walls,usea3/8”or10mmdrillbit.

! x6

WARNINGS

• THE TV MOUNT MUST BE FIRMLY ATTACHED TO A SOLID CONCRETE/

BRICK/WOOD WALL, OR WALL STUDS BEHIND DRYWALL.

• Tightenscrewssothatpartsarermlyattached,butdonotovertighten.

Overtighteningmaycauseunintendeddamageorweakeningofparts.

• Donotremoveorloosenanyscrewsuntiltheyarenolongerengaged

withthemount.DoingsomaycausetheTVtofall.

• Itishighlyrecommendedtohavethismountprofessionallyinstalled.

• Supports VESA up to 600 x 400mm.

• This mount is designed to hold a maximum of 132 lbs (60 kg).

TOOLS

Thefollowingtoolsarerecommendedforthisinstallation:

• Drill

• 5/32”drillbitfordrywall

• 3/8”or10mmdrillbitforconcrete

• Studnder

• Phillipsscrewdriver

PARTS

x4F Ø8

Ø5 x4D

x4C M5x15

B x4

M6x15

A x4

M8x15

x4E Ø6

Ø15xØ8x4.5

x4G

x2I M6x38

H x2

M6x20

M6x50 x6K

Ø10x50 x6J

x1M

N x2

x1L Level

Note: Parts A-G are used to attach

your TV to the brackets in Step 3,

but you will not need all of them. Use

the set that best ts your TV.

STEP 2

Attach Mount to Wall

• If mounting to a solid wall,

insertthesixwallanchorsintothe

holesdrilledinStep1,thenscrew

thebaseplatermlytothewall

withthesuppliedscrews.

• If mounting to drywall/studs,

screwthebaseplatermlytothe

wallwiththesuppliedscrews.

• We recommend drilling 4 holes at the top of the mounting plate,

and 2 at the bottom.

Ø10x50

x6J

M6x50

x6K

Towards Wall

FULL MOTION FLAT PANEL TV MOUNT FOR 28-65” TELEVISIONS

User’s Guide for Model TM65 v1568-01

• Attachthetwobracketstothe

rearofyourTV,hooksdown.

• Usetheincludedscrewsand

washers(PartsA-G)tosecurethe

brackettoyourTV.Findtheset

thattsyourTVanddiscardthe

rest.

• Therubberwashers(PartG)can

beusedasaspacerbetween

the TV body and the mounting

brackets, ifthemountingholes

ontheTVaretooshallowforthe

includedscrews.

STEP 4

Attach Television to Mount

ARTICULATION & RANGE OF MOTION

• AttachtheTV/brackettothemountonthewall,makingsuretormly

tightenthelowernuttothemounttosecuretheTV(donotovertighten

ordamageresult).

• ItishighlyrecommendedtouseatleasttwopeopletohangtheTV.

Optional Screws

& Washers

Tighten screw to secure TV brackets to mount

Make sure brackets are

hooks down

A-G

STEP 3

Attach Brackets to Television

PARTS A-G

center to center

MAX 600mm

180˚

MAX

400mm

8˚ up

12˚ down

643mm

N x2

H x2

M6x20

x2I

M6x38

Product Specifications
