Page 1/7
1
Installation Guide
AT-OME-CS31-SA-HDBT
AV Presentation
and Collaboration System
AT-OME-CS31-SA-HDBT
The Atlona AT-OME-CS31-SA-HDBT is an AV presentation and collaboration system for
classrooms and conference rooms. It features AV switching of remote and local sources, a mixer
amplier, and USB hub.
The switcher has one HDBaseT® input supporting extension of HDMI, Ethernet, power, control,
and USB 2.0 data up to 330 feet (100 meters) as well as two HDMI® inputs. Sources connected
to these inputs, such as laptops, computers, and document cameras, are routed to the HDMI
output connected to a projector or display. The amplier of the OME-CS31-SA-HDBT delivers
either two channels of 25 watts or a single channel of 50 watts into 4 or 8 ohms. It features one
balanced stereo audio input and two unbalanced stereo audio inputs with independent level
control for each. A balanced stereo line level output allows the mixed signal to be passed to
an assistive listening system or separate amplier. The OME-CS31-SA-HDBT’s USB system
integrates a USB 2.0 host over HDBaseT with a local USB 3.0 host and connections for four
peripheral devices such as cameras, speakerphones, interactive displays, keyboards, mice, or
storage devices.
IMPORTANT: Visit https://www.atlona.com/product/at-ome-cs31-sa-hdbt for the latest
rmware updates and User Manual.
1 x AT-OME-CS31-SA-HDBT
1 x Envelope of mating connectors for all captive-screw connectors
1 x Surface mount brackets
4 x rubber feet
1 x 24 V / 5 A power supply
1 x AC cord
1 x Insert w/ QR code
Package Contents
2
Installation Guide
AT-OME-CS31-SA-HDBT
HDBaseT IN
1
2 3
5V FWINPUT
PWR LAN LINK
IN1
RL
MIC L/R L/R
IN2 IN3
HDMI I N HOST AUDI O INAT- OME-CS31-SA-HDBT
SWIT CH ER WIT H
AUDI O AMPLIFIER
1 LED Indicators
Displays the current state of the unit:
PWR - LED will be red while the unit
is booting and green when operating
normally.
LAN - LED will be green when connected
to a switch or other LAN device.
LINK - LED will be green when connected
to an HDBaseT transmitter.
IN1 IN2 IN3, , - LED will be green when set
to the current input.
2 INPUT
Press and release this button to cycle
between each of the available inputs.
3 HDBaseT IN
Connect a category cable from this port
to a compatible HDBaseT transmitter or
switcher.
4 HDMI IN
Connect an HDMI cable from each of
these ports to an HDMI source.
5 HOST
Connect a USB cable from this port to the
host USB device.
6 MIC
This port is for future use.
7 VOICE L/R
Connect the included 5-pin captive screw
connector from this port to a balanced
analog audio input.
8 L/R
Connect a music player, Bluetooth
â„¢
receiver, or other unbalanced stereo
source to each of these 3.5 mm mini-
stereo ports.
9 5V
Provides +5 V USB power. Can be used
to attach Bluetooth
â„¢ audio adapters or
powered USB hubs.
10 FW
This USB-C port is used to update the
rmware. Refer to the User Manual for
more information.
Front Panel Descriptions
1 3 6 7 92 4 5 8
10
3
Installation Guide
AT-OME-CS31-SA-HDBT
HDMI OUTHUBAUDI O OUTAMP OUTPA SENSERS-232T RI GGER I/OLAN
100V
70V
25V
CLASS 2 WIRI NG
T RI GGER R
RXP
1
2
1
2
TX
LRL
24V 5A
Rear Panel Descriptions
1 24V / 5A
Connect the included 24 V / 5 A power
supply from this port to an available AC
electrical outlet.
2 LAN
Connect an Ethernet cable from either of
these ports to the LAN. The other LAN
port can be used to connect an Ethernet
cable to a display or other device.
3 TRIGGER I/O
Connect the included double-stack 4-pin
connector to this port. This port consists
of two separate ports: TRIGGER I/O 1
(top) and (bottom).TRIGGER I/O 2
4 RS-232
Connect the included double-stack 3-pin
captive screw connector to this port.
This port consists of two separate ports:
RS-232 1 RS-232 2 (top) and (bottom).
5 TRIGGER (PA SENSE)
Connect the included 2-pin captive screw
connector to this port. Supports audio
mute with contact closure or PA sense so
announcements can be heard clearly.
6 GND/25V/75V/100V (PA SENSE)
Connect the included 4-pin captive screw
connector from this port to a PA speaker
system.
7 Potentiometer (PA SENSE)
Adjusts the trigger voltage sensitivity.
8 AMP OUT
Connect the included 4-pin captive screw
connector from this port to a pair of
program / stereo speakers. Supports 2 x
25 watts @ 4/8 ohms amplier (stereo or
dual mono) or 1 x 50 watts @ 4/8 ohms
(bridged).
9 AUDIO OUT
Connect the included 5-pin captive screw
connector from this port to an assistive
listening device or additional amplier.
10 HUB
Connect up to 4 USB devices to these
ports.
11 HDMI OUT
Connect an HDMI cable from this port to
a display.
981 3 6 7 112 4 5 10
