Watson VM-148-HCS-R Manual

Watson Not categorized VM-148-HCS-R

Read below 📖 the manual in Italian for Watson VM-148-HCS-R (5 pages) in the Not categorized category. This guide has been helpful for 3 people and has been rated 4.5 stars on average by 2 users

Page 1/5
Thank you for choosing Watson Pro
Please read this user manual carefully, and keep
it for reference before using the battery.
AM/VM-99-HCS-R
AM/VM-148-HCS-R
Cine style
Li-ion Battery with LED
and 3-Stud or V-Mount
SAFETY INSTRUCTIONS
Make sure the battery is fully charged before use.
When not in use, remove the battery from its device. Some
electronic equipment will draw current even when the switch is off.
Do not short-circuit the terminals. This battery is protected with
an internal self-resetting fuse, but short circuits may still cause
severe damage to the battery.
Do not attempt to open the battery case under any circumstances.
Do not remove the battery from any equipment that is powered on.
Always power off your equipment before removing the battery.
Use the battery under proper environmental conditions: 14°F to
122°F (-10°C to 50°C) with a Relative Humidity (RH) less than 85%.
The battery may be warm during use or recharging. This is normal.
The battery should be charged up to 40% for storage longer than
one month, and should be charged every 6 months.
Keep the battery away from fire, heat, and high pressure.
Do not expose the battery to rain or moisture.
Do not drop the battery or subject it to strong shocks.
Keep this unit away from water and any flammable gases or liquids.
Clean the battery and terminals with only a clean, soft,
and dry cloth.
When operation time has noticeably decreased, the battery may
need to be replaced.
Keep this product away from children.
Store the battery in a cool, dry place.
PRODUCT FEATURES
High-powered li-ion cells provide constant output up
to 180 W and 15 A.
Battery-level LED indicators for remaining battery
capacity.
Built-in D-tap connector powers your camera
accessories.
5 V/1 A USB 2.0 output for USB-powered devices.
Built-in intelligent control circuit protects against
damage from current or voltage overload,
overheating, or short circuits.
OVERVIEW
. Battery-level LED meter
Shows remaining capacity of
the battery. When capacity
reaches less than 9%, the
leftmost LED will flash.
Battery-level check button
D-tap output
12 V, 10 A max
. USB output
Press the battery-level check
button to start charging or to
power your USB device.
Mounting interface: 3-stud
or V-mount
1
2
3
4
5
4
1
2
5
3

Product Specifications

Brand: Watson
Category: Not categorized
Model: VM-148-HCS-R
