Page 1/6

Desktop Monitor Stands

DS1FSS / DS2FSD / DS1FST

DS1FSS

DS2FSD

114mm

100mm

75mm

465mm

390mm

75mm

100mm

114mm

38mm 50mm

280mm

±180°

-45°

+45°

±90°

114mm

100mm

75mm

100mm

114mm

280mm

390mm

140mm

465mm

38mm 185mm

±90°

±180° ±90°

±45°

±180°

36mm

Desktop Monitor Stands

DS1FSS / DS2FSD / DS1FST

DS1FST

± °45

215mm

35mm

48mm

21 5 mm

75 m m

10 0 mm

11 3 mm

75 mm

10 0 mm

11 6 mm

340°

180°

± °45 360°

200mm

46 6 mm

31 6 mm

43 4 mm

1330mm

Desktop Monitor Stands

DS2FSD-2N DS1FSS DS1FST-1N

Dual Desktop Monitor Stand V7 Free Standing Desk Stand Single Triple Swivel Desk Stand Mount

GENERAL

Sku: 2GW319 8GA435 8J4517

Msrp: 79.99 USD 39.99 EUR, 39.99 USD 129.99 USD

Model: DS2FSD-2N DS1FSS DS1FST-1N

EAN: 0662919099126 0662919111187 0662919094626

Warranty: 5 years 5 years 5 years

Compliance: RoHS, UL RoHS RoHS

Country Of Origin: China China China

Package Includes: Mount, hardware, instruction manual Product, User's Guide, Hardware Product, User's Guide, Hardware

DESIGN

Display Size (per display): 13" to 32" Displays 13" to 32" Displays 10" to 27" Displays

Mount Type: Desk Desk Desk

Material: Steel, Aluminum, Plastic Steel Steel, Aluminum

Weight Limit: 8 kg 8 kg (17.6 lbs) 17.6 lbs

PACKAGE DIMENSIONS

Package Dimensions (L/W/H): 489 x 289 x 105 mm (19.25 x 11.38 x 4.13 in) 448 x 30 x 90 mm (17.64 x 1.18 x 3.54 in) 620 x 340 x 145 mm (24.41 x 13.39 x 5.71 in)

Package Weight: 11.11 lbs (5.04 kg) 3.36 kg (7.41 lbs) 17.42 lbs (7.9 kg)

PRODUCT DIMENSIONS

Product Dim (L/W/H): 913 x 280 x 465 mm (35.94 x 11.02 x 18.31 in) 390 x 280 x 465 mm (15.35 x 11.02 x 18.31 in) 1448 x 316 x 466 mm (57.01 x 12.44 x 18.35 in)

Product Weight: 9.7 lbs (4.4 kg) 2.78 kg (6.13 lbs) 15.21 lbs (6.9 kg)

TECHNICAL

Tilt: +35° ~ -35° +45° ~ -45° +45° ~ -45°

VESA Mount: 100 x 100 mm, 75 x 75 mm 100 x 100 mm, 75 x 75 mm 100 x 100 mm, 75 x 75 mm

Pan: +90° ~ -90° 180° +45° ~ -45°

Weight Limit (per display): 17.64 lbs (8 kg) 8 kg (17.6 lbs) 17.64 lbs (8 kg)
