Page 1/24
Owner’s Manual
1111 W. 35th Street, Chicago, IL 60609 USA • www.tripplite.com/support
Copyright © 2019 Tripp Lite. All rights reserved.
8-Port UHD 4K 60 Hz
HDMI Splitter with EDID
Model: B118-008E-UHD-2
Product Features 2
Package Contents 2
Ports 3
Installation 4
Operation 5
EDID Management 6
Troubleshooting 7
Warranty & 8
Product Registration
Español 9 • Français 17
WARRANTY REGISTRATION
Register your product today and be
automatically entered to win an ISOBAR
surge protector in our monthly drawing!
www.tripplite.com/warranty
2
Product Features
Package Contents
• Simultaneously transmit video and audio from an HDMI source to up to
eight monitors
• Supports UHD 4K x 2K video resolutions up to 4096 x 2160 @ 60 Hz
• Supports 36-bit Deep Color (12 bits per channel)
• Supports DTS-HD, Dolby® TrueHD, Dolby Digital Plus™ and LPCM 7.1
Channel Surround Sound audio
• HDCP 2.2 and HDMI 2.0 compliant
• Plug and play; no drivers or software required
• B118-008E-UHD-2 8-Port UHD HDMI Splitter with EDID
• External Power Supply (Input: 100-240V~50/60Hz, 0.6A; Output: 12V, 2A)
• Mounting Hardware
• Owner’s Manual
Optional Accessories:
• P568-Series High-Speed HDMI Cables
• P569-Series HDMI 2.0 Premium High-Speed Cables
• P566-Series HDMI to DVI Adapter Cables*
*When using an HDMI to DVI adapter cable, only the video signal will be transmitted to
the DVI monitor. Video resolutions will be limited to those supported by the adapter.
3
Ports
Front View
EDID DIP Switch
Power
Indicator
HDMI Output
Ports
HDMI Output
Ports
HDMI Input Port Power Input
(12V/2A)
Output
LEDs
Rear View
Output
LEDs
