Page 1/5
Ÿ16-Port Gigabit PoE+ Switch
TPE-TG160g
ŸQuick Installation Guide (1)
TPE-TG160 (V1) /07.30.2015
Minimum Requirements
ŸTPE-TG160g
ŸQuick Installation Guide
ŸPower cord
ŸRack mount kit
ŸComputer with network adapter installed
ŸRJ-45 Network cable
Package Contents
1. Before You Start
1
Optional Equipment
ŸEIA standard 19” rack
2. LEDs
LED Color Definition
Green
Red
Device is on
Device is off
The total PoE output power has reached maximum capacity, do not connect any
more PoE devices to the unit.
System has adequate power reserves to power another device
PWR
PWR Max
Green
There is an error with the PoE connection at this port
A gigabit connection has been detected
Data is being transmitted
Fan
An ethernet / fast ethernet connection has been detected
Green
Amber
LINK/ACT
No active connectionOff
Sequence
Solid
Off
Solid
Solid
Solid
Blinking
Solid
Off
Blinking Data is being transmitted
PoE
Red
Off
The fan has experienced a failure, and is not operational
The switch is connected and supplying power to a PoE device
Solid
Off The fan is operating normally
Amber
Off
Solid
No PoE device has been detected at this port
Off
2
3. Hardware Installation
Note: The maximum amount of power available is 30 Watts per port and 246 Watts total. If a power
overload has occurred, the Switch will prioritize the distribution of power by port (from lowest to highest).
That is, port 1 will receive the highest priority and port 4 will receive the lowest priority. The ports with lower
priority will have their PoE function disabled until sufficient power becomes available.
1 power adapter power adapter. Plug the power cord into the . Connect the to the TPE-TG160g and then
to a power outlet.
2. Connect an RJ-45 network cable from the TPE-TG160g to your computer's network port.
3 network . Connect an RJ-45 cable from a port on the TPE-TG160g to the port of the PoE device
(e.g. TV-IP310PI).
4: Verify the following LEDs are on: , and . Power PoE Status Link/ACT
1
2
3PoE
